This section provides an overview for conductivity meters as well as their applications and principles. Also, please take a look at the list of 26 conductivity meter manufacturers and their company rankings.
Table of Contents
A conductivity meter is a device to measure the electrical conductivity of an aqueous solution. Conductivity is a value that indicates the ease of flow of electric current in water, and the higher the concentration of ions in the water, the greater the value. A voltage is applied to two electrodes attached to the conductivity meter. The electrical conductivity is measured from the current and resistance value at that time.
Conductivity meters are available in desktop and portable versions. Portable conductivity meters are frequently used in the field because of the simplicity of measurement with a conductivity meter. Conductivity meters must be calibrated with potassium chloride standard solution before use.
Conductivity meters have a wide measurement range. Therefore, Conductivity meters are used in a wide variety of aqueous solutions, ranging from measurements of samples with very little ionic material and low conductivity, such as ion-exchanged water and pure water, for example, to measurements of samples with a high content of ionic material, such as seawater.
Conductivity meters are also used to analyze environmental water such as river water, lakes, and seawater, as well as wastewater from the processes of semiconductor, chemical, and pharmaceutical manufacturers, and to control water quality. They are also sometimes used in the food industry for simple salinity analysis.
There are two types of conductivity meters: contact and dielectric.
One is called the contact type, in which the electrode is in direct contact with the sample solution. Since particles or other substances adhering to the electrode of a contact-type conductivity meter can cause fluctuations in the measured value, it is used to measure solutions that do not contain solids or pure water with low electrical conductivity.
On the other hand, dielectric conductivity meters are used for solutions that contain many solid particles or foreign matter, or solutions that corrode the electrode. In a dielectric type, a coil is embedded in a resin, and an alternating current is applied to this coil to measure the electric conductivity from the strength of the induced electric field generated in the solution to be measured. The dielectric method can measure even corrosive liquids and solutions with high ionic concentrations because the coil is protected. However, it is not suitable for measuring minute electrical conductivity.
Conductivity meter is a device to measure electrical conductivity, which indicates the ease of current flow in a solution. The conductivity meter is immersed in a sample solution, and a voltage is applied to initiate the measurement. The amount of current produced by the application of this voltage increases with the ion concentration in the solution. Therefore, the electrical conductivity can be determined from the current value and resistance value.
Conductivity meters need to be calibrated before use. Potassium chloride standard solution is used for calibration. Once the standard solution has been used for calibration, it may be contaminated by substances adhering to the electrode surface, so the standard solution should be divided into smaller portions, and once used, the solution should not be reused.
*Including some distributors, etc.
Sort by Features
Sort by Area
Micro Quality Calibration Inc MQC) was founded in 1978 as a technology-oriented calibration, repair, testing, and first article inspection facility for precision measurement test equipment. MCQ follows in strict compliance of ISO-9000 (series 1, 2, 3, and 4) specifications. MCQ offers services in calibration, inspection testing, repair, database management, and analytics. Calibration services are often provided for automotive, electrical components, aerospace, and secure communications, for which MCQ is ISO 17025 accredited.
Sterling Sterlco was founded in 1916 and distributes under M&M Control Service, Inc. is a specialist in industrial control units. Industrial control units are in two basic varieties: steam control family and temperature control units. Steam Control units include steam traps, Y strainers, temperature control valves, hand radiator valves, boiler feed pumps, condensate pumps, and centrifugal pumps. Temperature control units include portable chillers, central chillers, and water and oil temperature control units. Additionally, Sterling also manufactures pump tanks.
AppMet, Inc was founded in 1993 in North Charleston, South Carolina. AppMet is a calibration and testing company offering dimensional, physical & mechanical, and electronic & electrical calibration services in climate-controlled laboratories as well as on-site calibrations when possible. AppMet is ISO/IEC 17025 as well as Full Service ISO-99001 certified. Electronic calibrations are made with all types of electrical and electronic test equipment from analog multimeters to RF spectrum analyzers. Physical and mechanical calibrations and tests are performed with equipment ranging from analytical balances to vacuum gages. Dimensional calibrations are performed with equipment ranging from 1-2-3 blocks to angle plates to thickness gages.
Tri-State Instrument Laboratory was established in Tulsa, Oklahoma in 159. Tri-State is a distributor and provider of calibration and related services. Tri-State also manufacturers voltage dividers, motor rotation indicators, and phase sequence indicators. Calibration services include calibration of various types off multimeters, clamp meters, electrical and resistance testers, power recorders, loop, process, and temperature calibrators, infrared and contact thermometers, and analog and digital panel meters. In addition to calibration services, Tri-State specializes in meggers, process calibrators, clamp meters, thermometers, multimeters, and other products such as digital counters, ,hour meters, and hard cases.
HealthStar was founded in 1983 in Braintree, Massachusetts. HealthStar is a distributor of manufacturing equipment, specializing in processing and packaging. HealthStar specializes in blow-fill-seal, in-line and rotary liquid & power filling, secondary packaging, tablet & capsule processing, sterile & aseptic filling, processing, && packaging, granulation & blending, tanks & reactors, and terminal sterilization. HealthStar services include blow-fill-seal rebuilding, partial to full plant liquidations, auctions, and appraisals, surplus equipment purchasing, equipment exchanges, and equipment search and referral.
Plastic Engineered Products, Co. is owned by the Ryan Herco Flow Solutions Company and is a a distributor of fluid handling, control and high value filtration systems for corrosive and ultrapure systems. PEP offers both sales as well as services. Sales offerings include tubing, hoses, measurement & control devices, housings, tanks, and pumps. Services include custom plastic & fiberglass fabrication while field servies include emergency repair as well as maintenance and testing as well as fabrication and welding.
NCI Clean, now part of North Central Instruments, began in 1995 as Innotech Products as a distributor for laboratory and cleanroom equipment. NCI Clean offers modular cleanrooms and products intended for use in cleanrooms such as flooring, paint, filters, curtains, and instrumentation. Other cleanroom equipment include air showers, surge isolation pods, desiccators, cleanbenches, fume hoods, spray guns, glove boxes, anti-fatigue mats, and shoe cleaners. Other equipment includes gowning room furniture and components, cleanroom apparel, microscopes, and supplies such as alcohols, swabs, and wipes.
Ryan Herco Flow Solutions was founded in the 1950s in California. RHFS sells and provides value added support for a wide variety of fluid handling and filtration needs. Product categories include tubing, hoses, piping, drain waste vent & containment, valves, measurement & control devices, fluid pumps, filters & housings, storage & containment tanks, heaters, mixers, and grating in addition to customized systems and material fabrication. Value added services include industrial service and repair of components, custom fabrication, and pump repair services.
Endress+Hauser Group is based in Switzerland and has over 15,000 employees worldwide. Endress+Hauser manufactures measurement instrumentation and provides services for industrial process engineering. Endress+Hauser’s customers come from various industries including chemical, life sciences, energy, and water. Endress+Hauser’s products include those for level measurement, pressure measurement, software, industrial communication technologies, and liquid analysis. Endress+Hauser also offers services including project and commissioning, support and education, maintenance, and performance optimization. The company has an assortment of online tools to assist customers in services such as product selection.
MOD-TRONIC Instruments Limited was established in 1972 in Brampton, Ontario, Canada. MTis a distributor of industrial sensors, transducers, heaters, controls, and instrumentation, primarily made in the USA as well as Japan, Switzerland, and Germany. MT’s customers are primarily in the aerospace, building automation, manufacturing, medical, military, oil and gas, and water treatment industries but also serves individuals. MT offers an above industry standard 5-year warranty and technical support on every product sold.
