Membrane filters are used to remove fine particles from solutions. Filtration using a membrane filter, also called microfiltration, can reliably remove particles larger than the pore size of the filter. However, membrane filters are prone to clogging, so rough filtration using a pre-filter is often performed before filtration.
Membrane filters are made of a wide variety of materials, including PTFE, PVDF, PES, cellulose mixed ester, and polypropylene. When using a membrane filter, it is necessary to select an appropriate membrane filter based on the chemical resistance of the filtering material, whether or not the components in the sample are adsorbed by the filter material, and whether or not the pore size of the filter is small enough for the particulates to be removed.
Membrane filters are made of membranes. Liquid filtration is routinely used in a variety of industries, including food and beverage, medical, electronics, chemical, and textile industries. Membrane filters are used in a process called microfiltration.
Microfiltration is a process that completely traps substances larger than the pore size (pore diameter) of the membrane, enabling stable removal of impurities from liquids. For this reason, microfiltration using membrane filters is used in the semiconductor industry, where even the smallest amount of foreign matter is unacceptable, and before filling, products are sold as solutions.
Membrane filters are made of a wide variety of materials. Examples of materials include PTFE (polytetrafluoroethylene), PVDF (polyvinylidene fluoride), PES (polyethersulfone), nylon, cellulose blend esters, and polypropylene.
All of these polymers vary in their resistance to organic solvents, acids, and bases and have very different chemical structures. Therefore, in addition to considering the durability of the solution to be filtered, the ease of sample adsorption on the membrane filter must also be taken into consideration.
Membrane filters can be compared to pre-filters. These are the same "filter" but have a different internal structure and particle trapping mechanism. Prefilters, also called depth filters, are made of glass or other fibrous materials that are pressed together. Therefore, the size of the flow path inside the filter is not constant. Also, during filtration, large particles are trapped by clogging in the middle of the flow path. However, if an excessive amount of material flows through the filter, the clogged particles may be pushed out and pass through the filter.
Membrane filters, on the other hand, have a specified maximum pore diameter, and no flow path can be larger than the pore diameter in the catalog. Therefore, particles larger than the pore diameter are captured on the filter surface and completely separated from the filtrate. However, since all particles accumulate on the filter surface, membrane filters are prone to clogging. In actual processes, filtration is often performed first with a pre-filter for simple filtration and then with a membrane filter.
*Including some distributors, etc.
Sort by Features
Sort by Area
baghouse.com was founded in the early 1980s and is headquartered in Las Vegas, Nevada. The company is a manufacturer of baghouse dust collection systems used across industries. The company’s product segments include baghouse filters, industrial dust collectors & dust collection systems, dust collector filter cages, and accessories including leak test supplies. The company’s services include baghouse filter replacement, maintenance programs, turn-key system installation, system audits, and leak testing. The company also offers technical advice and training courses to assist customers perform maintenance in-house.
Jaxon Filtration was founded in 1984 and headquartered in Franklin, Georgia. The company is a manufacturer of products designed to extend the life of petrochemical, provide wastewater filtration, and clean exhaust vapor. All of the company’s products are made in the United States and used in petrochemicals, liquid filtration, cutting fluids, and phosphate ester oil. The company’s product capabilities include filter elements, filtration systems, bag filter elements, and replacement elements that use media including diatomaceous earth, activated carbon, molecular sieve, and selexsorb acid.
PSM Industries is a family business founded in 1956 and is based in Los Angeles, California. PSM provides solutions in parts fabrication through powder metal technology. Through this, PSM serves industries including medical, sporting goods, food service, and aerospace. PSM Industries consists of 4 categories of divisions throughout the United States. High-Performance PM includes Pacific Sintered Metals, PM Engineered Solutions, and BestMetal. High Wear Carbides Includes PM Krupp High-Speed Steels and Yilik Precision Carbides. The other two categories are metal injection molding featuring PolyAlloys and engineered plastics featuring W.M. Guliksen.
Hilliard Corporation was founded in 1905 and headquartered in Elmira, New York. The company is an engineer, manufacturer, and distributor of motion control, braking systems, and filtration products to industries such as power generation, oil & gas, refinery, and steel in their ISO 9001:2015 certified manufacturing facilities. The company provides direct contact between customers and engineers and has the manufacturing and design capabilities to customize orders to meet any challenge in the motion control and filtration industries, whether the end products are industrial clutches, engine starters, or braking systems.
The Titus Company was founded in 1986 and is based in Morgantown, Pennsylvania. The Titus Company provides expertise for compressed air solutions for private companies in manufacturing, concrete, and chemical applications as well as government institutions such as the Royal Navy. Product offerings include blowers & vacuum products, chillers & coolers, compressors, dehydrators, dryers, dust collection equipment, energy management tools, filters, gas generators, pumps, and accessories. The Titus Company also offers maintenance, service, repair, system analysis, system dieting, monitoring, as well as installation services.
Ransohoff was founded in 1916 and is located in Cincinnati, Ohio. Today, the company is a division of Cleaning Technologies Group. Cleaning Technologies Group is a provider of innovative process technologies to precision and industrial global manufacturing markets. Ransohoff is a manufacturer of aqueous and solvent-based parts cleaning systems as well as a complete line of recyclable aqueous chemistries and waste minimization technologies. The company serves market sectors including electrical components, optics, general manufacturing, heavy-duty trucks, and off-road vehicles. The company offers industrial parts washers, ultrasonic and megasonic cleaning systems, benchtop cleaning systems, and electronic cleaning systems.
Beltran Technologies is based in Brooklyn, New York, and has a 50-year history in designing and engineering innovative air pollution control, gas cleaning systems, and bioenergy solutions for a vast range of industrial applications. Beltran systems include advanced wet and dry electrostatic precipitators, scrubbers, fume coalescers, and biomass gasification. Uses include liquid, solid, and precious metal recovery; prevention of downstream contamination, and stack opacity. Beltran services achieve cost savings, emission control, and energy efficiency for customers.
Refraction Technologies Corp. was founded in 1984 and is based in Newark, New York. The company is an ISO 9001:2015 and ITAR-certified manufacturer of ceramic-based products for industries such as aquaculture, chemical processing, pumps & valves, water treatment, and wire & cable manufacturing. The company has two product segments: Porous Ceramics and Zirconia Ceramics. Porous Ceramics includes fasteners and components based on aluminum oxide and silicon carbide. Zirconia Ceramics includes components with strong corrosion resistance, and increased strength, while weighing less than conventional materials.
Clean Liquid Systems is headquartered in Houston, Texas, and is a national supplier of clean air, water, and filtration systems used in human and pet food processing, liquid bottling, and oil and gas industries. The company’s product categories include liquid filters, natural gas, pollution control units, and hydroponic filters. Liquid and natural gas filters are designed for contaminant removal to increase efficiency and reduce pollution. Hydroponic filters serve hydroponic farming on both individual and commercial scales.
Becker is a service provider and stocking distributor of products and equipment for aviation refueling, petroleum handling, process, and industry. Becker & Associates was founded in 1967 and is headquartered in East Dundee, Illinois. Becker has two primary divisions, aviation and industrial. The aviation division provides aviation refueling equipment, fuel quality control testing equipment, fuel monitors, and more. The industrial division includes various filters and elements, spill kits, desiccants, and more. Becker’s manufacturers include Des-Case, Jonell, Facet International, Eaton, and Shawndra Products.
Ranking as of June 2023 in United States of America
Derivation MethodRank | Company | Click Share |
---|---|---|
1 | Advantec MFS Inc | 33.3% |
2 | Shelco Filters Div., Tinny Corp. | 33.3% |
3 | Jaxon Filtration | 16.7% |
4 | FlowTech Corporation | 16.7% |
Ranking as of June 2023 Globally
Derivation MethodRank | Company | Click Share |
---|---|---|
1 | Advantec MFS Inc | 28.6% |
2 | Jaxon Filtration | 28.6% |
3 | Shelco Filters Div., Tinny Corp. | 28.6% |
4 | FlowTech Corporation | 14.3% |
Derivation Method
The ranking is calculated based on the click share within the membrane filter page as of June 2023. Click share is defined as the total number of clicks for all companies during the period divided by the number of clicks for each company.Number of Employees
