This section provides an overview for sfp modules as well as their applications and principles. Also, please take a look at the list of 13 sfp module manufacturers and their company rankings. Here are the top-ranked sfp module companies as of December, 2024: 1.EnGenius Technologies, 2.StarTech.com Ltd., 3.Advantech Co., Ltd..
Table of Contents
SFP (small form-factor pluggable) modules are optical transceivers that convert electrical signals into optical signals.
They are mainly used in data communication applications to connect network devices. SFP modules can be used with UTP cables, which have a transmission distance limit of 100 meters, and can be extended beyond this limit.
It is specified by the multi-source agreement (MSA) and supports gigabit ethernet, SONET and other communication standards.
SFP modules are used to convert electrical signals into optical signals; with SFP modules, transmission media such as multi- and single-mode fiber, twisted pair cables, and coaxial cables can be connected with the required distance length and transmission speed.
They are also used in "storage interface cards" called HBAs or fibre channel storage switches, and support a wide range of speeds from 2 to 8G. Compact SFP Modules offer a variety of fiber-optic connections.
These low-cost modules are useful for increasing the flexibility of devices, such as switching hubs, routers, and firewalls. SFP Modules that provide fiber-optic connectivity are also characterized by their resistance to noise. Therefore, they are used to prevent communication problems in environments with many noise sources.
The following components make up the SFP module:
The TOSA converts the electrical signal into an optical signal for transmission, and the ROSA converts the optical signal into an electrical signal for reception. The CDR matches the signal on the receiving side with the signal on the transmitting side. The TIA processes the current signal converted by the ROSA into a voltage signal of a specific amplitude. The LA processes this output amplitude into a voltage signal of equal amplitude.
The LDD converts the clock signal output from the CDR into the corresponding modulation signal, which drives the laser to transmit an optical signal. The MCU is responsible for monitoring the operating status of the optical module and maintaining optical communications. Specifically, the MCU monitors parameters related to software operation, temperature, voltage, current, receiving power, and transmitting power in real time to determine the operating state of the optical module.
There are two types of SFP: SFP Fiber Module and SFP Copper Module.
Most SFP fiber modules are either CWDM (Coarse Wavelength Division Multiplexing) SFP or DWDM (Dense Wavelength Division Multiplexing) SFP, with CWDM using wide channel spacing and a maximum transmission distance of 120 km and DWDM using high-density channel spacing and a maximum transmission distance of 200 km.
There are three types of SFP Copper Modules: 1000BASE-T, 10/100BASE-T, and 10/100/1000BASE-T. The operating distance for 1000BASE-T is 100 m over twisted pair cable; for 10/100BASE-T and 10/100/1000BASE-T, it is 100 m over copper twisted pair cable. It is important to select the SFP Module according to the required operating distance.
When using SFP modules, the most important thing to consider is compatibility.
You must be very sure that the SFP module is compatible with the device to which it will be connected.
The operating environment and maintenance methods are important to prolong the service life. Avoid damaging end-faces, plugging in lightly, and using in proper humidity.
*Including some distributors, etc.
Sort by Features
Sort by Area
EnGenius Technologies Inc., founded in 1999 and headquartered in Costa Mesa, California, United States, is a developer and manufacturer of wireless voice and data communication devices. The company specializes in providing cloud-driven connectivity solutions, with products that include network switches, VPN routers, and point-to-point Wi-Fi access points. It also produces on-premise managed network controllers and a range of VoiP solutions. These products are designed to provide small and midsize businesses with communication and data transfer devices with enterprise-grade security.
Shenzhen Nufiber Systems Technology Co. Ltd., founded in 2003 and headquartered in Shenzhen, China, is a manufacturer of fiber optic equipment and HD network transmission devices. The company's main product categories include switches, transceivers, and transmission media converters, with products that include active optical cable, fiber-to-Ethernet converters, and Ethernet over coaxial extenders. It also offers POE switches, DVI/HDMI fiber optic extenders, and digital video fiber converters. These technologies are widely used in data centers and security monitoring systems. The company's services include consulting for custom network assembly and installation.
Liverage Technology Inc., established in 2003 and headquartered in Taiwan, China, is a manufacturer of fiber optics components, transceiver modules, and measurement equipment. The company’s products include optical test and measurement tools such as BER testers and fiber optics testing hubs, and various optical transceivers like QSFP28, SFP+, and SFF. Its core technologies encompass optical packaging, customized manufacturing, and testing equipment manufacturing, serving defense, aerospace, and oil exploration industries. The company has received prestigious awards like the 2016 BC Award at Computex and the 2015 Computex d&i award.
Maiwe Communication, established in 2001 and headquartered in Wuhan, China, is a manufacturer specializing in industrial internet communication devices. The company's product portfolio includes layer 2 rackmount unmanaged Ethernet switches, serial isolaters and repeaters, industrial network management software, embedded VDSL Ethernet extenders, wireless AP/access controllers, and more. These products find applications in various industry solutions, including rail transit, smart cities, the state grid, oil mining, and industrial automation. Its products have earned international certifications, such as CE, FCC, and RoHS.
Shenzhen htfuture Co., Ltd is a fiber optic products and WDM systematic solution manufacturer founded in Shenzhen, China in 2015. The company specializes in multiplexers, transceivers, patch cords and converters. Its products are used in industries, such as telecommunication, roadway safety, cloud computing and data centers. Its goods are used on a worldwide scale, but the manufacturer's main markets are China, Western Europe, South America and Southeast Asia. The firm is ISO 9001:2015 certified and holds multiple other certificates of compliance.
StarTech.com Ltd. (STC) is a Canadian manufacturer of IT connectivity products that was established in London, Ontario in 1985. The company produces hard drive enclosures, docking stations, and display adapters, as well as various cables using different connector standards. These are used to provide connectivity between computers, smart devices, and peripherals in home and company offices. STC products are mainly used by clients in information technology, education, and multimedia editing or production
Advantech Co., Ltd., established in 1981 in Neihu District, Taipei, is a pioneering manufacturer and designer of a range of products, solutions, and services. The company boasts an extensive product portfolio that includes system integration, customer-centric design services, cutting-edge embedded systems, automation products, and global logistics support. Its aim is to usher in an era of an intelligent planet through its automation and embedded computing products and solutions. These diverse products and services empower smarter ways of working and living to enhance the quality of life and productivity across various industries.
Versitron is a manufacturer of video, voice, and data communication products established in 1958 and based in Newark, Delaware, USA. The company offers fiber optic network switches for various network speeds and port sizes, fiber optic media converters for transitioning between Ethernet and fiber connections, and hot-swappable SFP modules with data rates up to 10Gbps. It also offers its Versivision brand data transmission module supporting various HD video formats. The company’s products are used in the retail, commercial office, and banking sectors.
Shenzhen HDV Photoelectron Technology Ltd., established in 2012 and based in Shenzhen, Guangdong, is a manufacturer and supplier of optical fiber communication equipment. Its product line includes Ethernet switches, fiber switches, and fiber transceivers, catering to diverse applications in the FTTH field. With a global reach, its products have been distributed to over 100 countries and regions. The compNY holds the ISO9001 quality system certification, along with other product certificates including FCC, RoHS, and Anatel.
Perle Systems, founded in 1976 and based in Princeton, NJ, USA, is a manufacturer and supplier of device networking and Internet of Things (IoT) connectivity hardware. The company's product range includes IRG 5G / LTE Routers, Industrial Switches, Console Servers, and Fiber Media Converters. These products establish network connectivity, securely transmit information, and remotely control IT equipment. They primarily serve industries such as telecommunications, manufacturing, and information technology. In addition to its product offerings, it provides setup, technical support, and equipment management services.
Ranking as of December 2024
Derivation Method| Rank | Company | Click Share |
|---|---|---|
| 1 | EnGenius Technologies |
24.2%
|
| 2 | StarTech.com Ltd. |
11.7%
|
| 3 | Advantech Co., Ltd. |
11.5%
|
| 4 | Perle |
10.9%
|
| 5 | Versitron |
7.9%
|
| 6 | Liverage Technology Inc. |
7.6%
|
| 7 | Shenzhen htfuture Co., Ltd |
6.9%
|
| 8 | Shenzhen Nufiber Systems Technology Co., Ltd. |
5.6%
|
| 9 | Wuhan Maiwe Communication Co., Ltd. |
4.3%
|
| 10 | Shenzhen HDV Photoelectron Technology Ltd. |
3.6%
|
Derivation Method
The ranking is calculated based on the click share within the sfp module page as of December 2024. Click share is defined as the total number of clicks for all companies during the period divided by the number of clicks for each company.Number of Employees
Newly Established Company
Company with a History
*Including some distributors, etc.
*Including some distributors, etc.
| Country | Number of Companies | Share (%) |
|---|---|---|
|
China
|
6 | 66.7% |
|
United States of America
|
1 | 11.1% |
Japan
|
1 | 11.1% |
|
Taiwan
|
1 | 11.1% |
65 products found
65 products
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) Lightning protection (6KV lightning protector) is installed as standard on the...
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 12 hours ago
Standard Response
1G/2.5G/5G/10Gbps compatible
Kaiko Electric Co., Ltd.
20+ people viewing
Standard Response
IP30 standard compliant ■Lightning protection Equipped with 2KV surge protection on TP port
Kaiko Electric Co., Ltd.
20+ people viewing
Last viewed: 9 hours ago
Standard Response
10GBASE-R compatible
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
1000BASE-T compatible
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
■Features ・1000BASE-X compatible ・100/1000BASE-X compatible (DR only) ・SFP-31-D series supports operating temperature of -40℃~85℃ ・Compatible w...
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 18 hours ago
Standard Response
IP30 standard compliant Equipped with 3 operation modes ■Switch mode Compatible with a wide range of network construction by utilizing the switch ...
Kaiko Electric Co., Ltd.
40+ people viewing
Last viewed: 11 hours ago
Standard Response
IP30 standard compliant
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 10 hours ago
Standard Response
IP30 standard compliant Equipped with 3 operation modes ■Switch mode Compatible with a wide range of network construction by utilizing the switch ...
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 6 hours ago
Standard Response
IP30 standard compliant
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 18 hours ago
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) Lightning protection (6KV lightning protector) is installed as standard on the...
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 19 hours ago
Standard Response
IP30 standard compliant ■Lightning protection Equipped with 2KV surge protection on TP port
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 56 minutes ago
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) Lightning protection (6KV lightning protector) installed as standard on all TP...
Kaiko Electric Co., Ltd.
30+ people viewing
Last viewed: 1 day ago
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) ・Lightning protection (6KV lightning protector) installed as standard on all ...
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) Lightning protection (6KV lightning protector) installed as standard on all TP...
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
IP40 standard compliant ■Lightning protection (Lightning protector) ・Lightning protection (6KV lightning protector) is installed as standard on t...
Kaiko Electric Co., Ltd.
30+ people viewing
Standard Response
IP30 standard compliant ■Lightning protection (Lightning protector) Lightning protection (6KV lightning protector) is installed as standard on the...
HARTING Technology Group
270+ people viewing
Last viewed: 12 hours ago
Standard Response
■ Characteristics ・ SFP 2, 4, 8, 12 ports 100/1000BASE-X ・ RJ45 8/16 Port 10/100/1000BASE-T (X) ・ IEEE 1588v2 PTP ・ Modbus-TCP, Ethernet/IP, Pr...
3 models listed
HARTING Technology Group
260+ people viewing
Last viewed: 8 hours ago
Standard Response
■ Characteristics ・ SFP 2, 4, 8 ports 100BASE-X ・ RJ45 8/16 Port 10/100BASE-T (X) ・ IEEE 1588v2 PTP ・ Modbus-TCP, Ethernet/IP, Profinet CC-B ・...
3 models listed
HARTING Technology Group
230+ people viewing
Last viewed: 15 hours ago
Standard Response
■ Characteristics ・ SFP 2, 4, 8 ports 100/1000BASE-X ・ RJ45 8/16 Port 10/100BASE-T (X) ・ IEEE 1588v2 PTP ・ Modbus-TCP, Ethernet/IP, Profinet CC...
3 models listed
Cybernetech Co., Ltd.
80+ people viewing
Last viewed: 15 hours ago
Standard Response
5.0 Company Review
■Model EX41922 series Two 1,000BASE SFP ports for daisy-chain or Alpha-chain applications ・SFP port supports 100Mbps and 1,000Mbps SFP transceiver...
Yokoo Co., Ltd.
120+ people viewing
Last viewed: 6 hours ago
Yokoo original small optical module (photo-electric conversion module) ■Compact optical transmitter/receiver (transceiver) module with LC compatib...
Yokoo Co., Ltd.
300+ people viewing
Last viewed: 3 hours ago
■Yokoo original “Optical device (optical module & optical transceiver)” From telecommunications to optical communications, making "optical" communi...
4 models listed
Special Electronic Circuit Co., Ltd.
70+ people viewing
Last viewed: 1 hour ago
Trenz Electronic TEF0008 is an FPGA-mezzanine card (FMC) based on the VITA 57.1 FMC HPC standard with four SFP+10 GBit ports for fiber optic SFP mo...
Connection Technology Systems Co., Ltd.
350+ people viewing
Last viewed: 3 hours ago
Multi -mode, single mode, 2 core/1 core, long -range models are available. It can be used on switches and media converters that support SFP modules...
8 models listed
Nippon Weidmuller Co., Ltd.
20+ people viewing
Last viewed: 1 day ago
■Transfer industrial data reliably and flexibly between devices in an Industrial Ethernet network The ideal connectivity solution for data communic...
Connection Technology Systems Co., Ltd.
190+ people viewing
Last viewed: 1 day ago
Multi -mode, single mode, 2 core/1 core, long -range models are available. It can be used on switches and media converters that support SFP modules...
FXC Co., Ltd.
20+ people viewing
Last viewed: 1 day ago
■Summary ・FXC optical modules are available in a lineup that supports QSFP28/QSFP+/SFP28/SFP+/SFP. ・There are also models that support communicat...
D-Link Japan Co., Ltd.
200+ people viewing
Last viewed: 4 hours ago
Features ■QSFP28 optical transceiver for 100Gbps high-speed communication This series is a QSFP28 optical transceiver that connects a 100 Gigabit s...
2 models listed
FXC Co., Ltd.
20+ people viewing
Last viewed: 1 day ago
■Summary ・FXC optical modules are available in a lineup that supports QSFP28/QSFP+/SFP28/SFP+/SFP. ・There are also models that support communicat...
