25 Servo Motor Reduction Drive Manufacturers in 2024

This section provides an overview for servo motor reduction drives as well as their applications and principles. Also, please take a look at the list of 25 servo motor reduction drive manufacturers and their company rankings. Here are the top-ranked servo motor reduction drive companies as of November, 2024: 1.ondrives us, 2.Heidrive GmbH, 3.Atlanta Drive Systems.

Table of Contents

What Is a Servo Motor Reducer?

A servo motor reducer (servo motor gearbox) is a device that reduces the rotational speed of the output shaft of a servo motor by means of gears to obtain torque proportional to the reduction ratio.


Figure 1. Servo motor reduction drive

Some models have a hollow output shaft that allows cables and other components to pass through.

The greatest advantage of using a servo motor reducer is that it allows a small motor to produce a large amount of torque.

If you try to operate a device with a servomotor alone, you will need a large output servomotor, which will increase the overall weight and size of the device. The use of servo motor reducers, on the other hand, can generate 4 to 100 times as much torque as a servo motor alone. This eliminates the need for large motors, making the equipment smaller and less expensive.

Understanding the type of reducer, its features, and product specifications, and selecting the right gear and reduction ratio for the application are important factors in configuring equipment that uses Servo motor reducers.

A similar concept also exists for products called geared motors.

Uses of Servo Motor Reducers

Servo motor reducers are mainly used in automated devices that run in factories.

Specific specification applications include the following:

Principle of Servo Motor Reducers

Servo motor reducers contain gears. The gears change the power obtained from the output shaft of the servomotor as follows.

  • Decreases the rotation speed by (1/reduction ratio) of the gear
  • Torque is increased in proportion to the reduction ratio

Let's take the gear below as an example to illustrate.


Figure 2. Principle of servo motor reduction drive

Consists of two gears: (1) Gear 1 to Gear 2 (reduction ratio: 3/1=3) and (2) Gear 3 to Gear 4 (reduction ratio: 7/3≒2.33).

The reduction ratio of this gear combination is:

(Reduction ratio of ①) × (Reduction ratio of ②) = 3/1 × 7/3 = 7

The reduction ratio of this gear combination can be calculated as follows.

This servo motor reducer changes the power of the output shaft of the reducer as follows.

  • Rotation speed is reduced to 1/7
  • Torque increases by a factor of 7 (Note 1)

(Note 1) Strictly speaking, the torque on the output shaft will be smaller than 7 times due to gear friction and other losses. For simplicity, losses are ignored here.

Types of Servo Motor Reducers

Servo motor reducers are broadly classified into two types: orthogonal-axis and parallel-axis.

In orthogonal-axis reducers, the output shaft of the servo motor reducer is orthogonal to the output shaft of the reducer. The gears used in the orthogonal shaft reduction gears are mainly worm gears and hypoid gears. In parallel shaft reduction gears, the output shaft of the servo motor reducer is parallel to the output shaft of the reducer. Gears used in parallel shafts are mainly planetary reduction gears.

The features of each are described below.

1. Worm Gear (Orthogonal Shaft)

It is characterized by high strength, high quietness, and is easy to make the output shaft hollow. it can be combined with motors of about 0.2~15kW, and the reduction ratio range is about 1/10~1/60.

2. Hypoid Gear (Orthogonal Shaft)

Compared to worm gears, they are characterized by high efficiency. They can be combined with motors of about 0.2~11 kW, and the reduction ratio range is about 1/5~1/200.


Figure 3. Hypoid gear

3. Planetary Reduction Gear (Parallel Shaft)

It features high efficiency, and the reduction ratio can be increased by increasing the number of stages. 0.2~3kW motors can be combined, and the reduction ratio range is approximately 1/3~1/100.

List of 25 Servo Motor Reduction Drive Manufacturers

*Including some distributors, etc.

Sort by Features

  • Default
  • Company Size: largest first
  • Year Founded: oldest first
  • Year Founded: earliest first

Sort by Area

  • United States of America
  • China
  • Germany
  • India
  • Japan
  • Taiwan
    • Redex USA
      • United States of America Address: 1705 Valley Road Ocean Township, New Jersey, United States of America

      Manufacturer Overview

      Redex USA, established in 1980 and based in New Jersey, USA, is a manufacturer of motion control components and systems. The company provides gearboxes and solutions to be used on industrial machinery. Its product portfolio includes servo planetary reducers, 2 speed spindle gearboxes, clutches & torque limiters, automatic lubrication systems and magnetic particle brakes. The company is a part of Redex group that manufactures precision cold rolling mills and strip processing technologies such as lines and equipments for carbon steel, stainless steel, aluminium and other non-ferrous metals strip producers.

    • DieQua Corporation
      • United States of America Address: 180 Covington Drive Bloomingdale, Illinois, United States of America

      Manufacturer Overview

      DieQua Corporation, a Bloomingdale, US-based company founded in 1980, is a manufacturer and supplier of sequential gearboxes as well as various motion control and power transmission drive components. The company presents spiral bevel gearboxes, servo gearheads, speed reducers, and shaft phasing and variable speed gearboxes. It also produces cycloidal reducers, screw jack systems, and zero backlash couplings and line shafts. The bevel gearbox design provides high precision for motion control and rugged construction to withstand rigorous dynamics. It is an AHTD member, PTRA member, MCMA member, Lubriplate partner, and IQS partner.

    • ondrives us
      • United States of America Address: 216 North Main St.Freeport, New York, United States of America

      Manufacturer Overview

      Ondrives US, founded in Freeport, NY, in 2011 is a manufacturer of standard, modified, and custom precision gears, gearboxes, pulleys and mechanical components. The company's product portfolio includes gear hobblers, gear shapers, CNC vertical mills, bar fed CNC lathes and laser engraving. The company serves industries such as Oil and Gas, Aerospace and Defense, Automotive and Transportation, Construction, and Power Generation. The company also provides services including two dimensional drawings of 3D CAD models, product selection, national distribution and customer support.

    • ElectroCraft, Inc.
      • United States of America Address: 2 Marin Way, Suite 3 Stratham, New Hampshire, United States of America

      Manufacturer Overview

      ElectroCraft Inc., established in 1960 and headquartered in Stratham, United States of America, is a supplier of application-engineered fractional-horsepower motor and motion products. The company provides DC motors, motor drives, linear actuators, and brush motors. It also delivers AC motors, gear motors, mobile drivetrains, and cables. It provides advanced precision solutions for the lowest cost of ownership for the largest brands and the newest cutting-edge companies. The products are used for medical equipment, laboratory automation, mobile robotics, industrial automation, agricultural automation, and military & defense industries. It serves North America, Europe, the Middle East, Africa, and Asia markets.

    • Atlanta Drive Systems
      • United States of America Address: 1775 Route 34, Unit D-10 Farmingdale, New Jersey, United States of America

      Company Overview

      Atlanta Drive Systems, founded in 1943 and located in Farmingdale, New Jersey, is a supplier of drive systems.   The company’s broad range of products includes gear racks, pinion ears, servo reducers, linear actuators, and washdown gearboxes. These products play a fundamental role in automation and robotics for precise and controlled movement, industrial machinery for applications like material handling and manufacturing, motion control for regulating speed and torque, linear motion systems for accurate positioning, and the food and beverage industry. The company’s products are used to enable precise movement, control, and efficiency in mechanical and automated systems across diverse sectors.

    • Mitsubishi Electric Corporation
      • Japan Address: Tokyo Building,2-7-3, Marunouchi, Chiyoda-ku, Tokyo, Japan

      Manufacturer Overview

      Mitsubishi Electric was established in Japan in 1921 and headquartered in Tokyo. The company’s Semiconductors & Devices division is a manufacturer of products serving several industries ranging from home appliances and automotive to renewable energy and optical fiber communication. The company’s products are divided into 4 product segments: power devices, high-frequency devices, optical devices, and infrared sensors. Power devices encompass motion controls, most home appliances, and SiC applications. High-frequency devices include satellite communications systems, radios, and base transceiver stations. Optical devices include projector light sources and optical fiber communication. Infrared sensing systems include MeIDIR thermal sensors.

    • NER GROUP
      • China Address: Wanshoushan Road Yantai City, Shandong, China

      Manufacturer Overview

      NER GROUP CO., established in 1993, is a China-based manufacturer and supplier specializing in industrial gearboxes and electric motors. The company’s product portfolio includes cycloidal geared motors, cycloidal gear motor reducers, helical-worm shaft gear motors, electromotors, and more. These power transmission products find diverse applications in industries such as mining, energy, construction, pharmaceuticals, and food sectors. The company holds ISO9001:2000, ISO14001:2004, and OHSAS18001:1999 certifications and has a vast network of branches across China, serving clients locally and worldwide.

    • Heidrive GmbH
      • Germany Address: Starenstraße 23,Kelheim, Bavaria, Germany

      Manufacturer Overview

      Heidrive GmbH, established in 1938 in Schwabach, Germany, is a manufacturer and supplier of quality electric drive systems. The company's main products include motors, gears, and integrated drive solutions used in various industries such as automation, robotics, and medical technology. Heidrive's motors and gears play a vital role in delivering precise and efficient motion control to a wide range of applications. With its resilience to efficiency and reliability, Heidrive aims to meet the unique needs of its customers and provide them with tailor-made solutions for their specific requirements.

    • SESAME MOTOR CORP.
      • Taiwan Address: 599, Sec. 1, Hemu Rd., Shengang, Taichung, Taiwan

      Manufacturer Overview

      SESAME MOTOR CORP., a company founded in 1990 and headquartered in Taichung, Taiwan, is a manufacturer of precision motors and motion control solutions. The company specializes in providing stepper motors, servo motors, and planetary gearboxes for various industries, including robotics, automation, and manufacturing. Their products are known for their efficiency, and precise control, enabling precise motion in a wide range of applications. They also provide customer services, offering technical support, customization options, and communication to meet clients’ needs.

    • MIKI PULLEY CO., LTD.
      • Japan Address: 10-41 Imaiminami-cho Nakahara-ku, Kawasaki-shi, Kanagawa, Japan

      Manufacturer Overview

      Miki Pulley Co., Ltd., founded in 1939, is a manufacturer and provider of solutions for power transmission and control problems, headquartered in Kawasaki City, Japan. They manufacture various products essential for all industries, including couplings for high-precision power transmission, electromagnetic clutches and brakes for power transmission when energized, and speed changers and reducers for controlling the speed of machinery. They also offer inverters, linear shaft drives, rotation speed indicators, torque limiters, and ROSTA rubber springs.

    • Matex Co., Ltd.
      • Japan Address: 1-125, Mizukoshi, Yao-City, Osaka, Japan

      Manufacturer Overview

      Matex Co., Ltd., established in 1921 and headquartered in Yao City, Osaka, Japan, is a manufacturer of precision engineering solutions. The company offers planetary gear reducers, electric actuators, injection molding products, plastic injection molding, and precision metal processing. These products cater to a multiple industries, such as robotics, automotive, and industrial machinery, and are used in applications ranging from home appliances to industrial facilities. It upholds rigorous quality standards, which are underscored by its possession of ISO 9001 and ISO 14001 certifications.

    • Transmission Machinery Co., Ltd.
      • Taiwan Address: No. 17, Alley 31, Lane 69, Xingnong Rd., Shanhwa Dist., Tainan City, Taiwan

      Manufacturer Overview

      Transmission Machinery Co., Ltd.,established in 1983 and headquartered in Tainan, Taiwan, is a manufacturer of types of speed reducers, cyclo drive & cycloidal gearbox. The company's products consist of helical bevel gearbox, planetary gearbox, cycloidal drive, robotics speed reducers, cyclo drive for servo motors and cyclo derivatives. The speed reducers designed for heavy industries can be used for automation to replace manual and less flexible automated processes. The epicyclic and cycloidal speed reducers find application in travel motors, robotic systems, pumps, mixers and conveyors. The company has two production facilities with a distribution network in Asia, Australia and South america.

    • Tsubakimoto Chain Co.
      • Japan Address: Nakanoshima Mitsui Building, 6F, 3-3-3 Nakanoshima, Kita-ku, Osaka, Japan

      Manufacturer Overview

      Tsubakimoto Chain Co., established in 1941 and headquartered in Osaka, Japan, is a manufacturer of chains for power transmission, transportation use, and variable speed reducers. The company offers a wide range of products, including conveyor chains, lifters, overload protectors, bulk handling systems, and more. It also offers roller chains, timing chains, linear actuators, and metalworking chip handling. Its product is designed to be resistant to particulate abrasion. The company has been certified as an Eco-First Company by the Ministry of the Environment. It serves industries such as steel, automotive, machine tools, food, and environmental sanitation equipment.

    • MICROTECH LABORATORY INC.
      • Japan Address: 8-1-46 Honcho, Kamitsuruma Sagamihara-shi Kanagawa, Japan

      Manufacturer Overview

      MICROTECH LABORATORY INC. is a designer and manufacturer of rotary encoders established in 1981 and headquartered in Kanagawa, Japan. The company offers rotary encoders, micro-linear scales, digital counters, and DD motors. It has a wide range of space-saving products, such as extremely small, high-resolution, and large-caliber hollow shaft encoders. The company's products adhere to ISO 9001 quality standards and cater to diverse applications, including industrial equipment, humanoid robots, medical equipment, semiconductor fabrication equipment, and digital broadcasting video equipment. It also provides custom-made encoders to meet the specific needs of its customers.

    • SAKANISHI SEIKI Co.,Ltd.
      • Japan Address: 1-32-1 Nanakuni, Hachioji-shi, Tokyo, Japan

      Manufacturer Overview

      SAKANISHI SEIKI Co., Ltd., established in 1945 and based in Hachioji, Tokyo, Japan, is a manufacturer specializing in the design and assembly of precision speed reducers and mechanical units. Its product offerings includes the V Series for applications, C Series for low-noise reducers, and custom-built gear products. Its capabilities include machining and assembly of precision components, and does distinction of high-mix, low-volume production. Its products plays a crucial role in delivering tailored mechanical solutions and precision gear technology.

    • Sumitomo Heavy Industries, Ltd.
      • Japan Address: ThinkPark Tower, 1-1 Osaki 2-chome, Shinagawa-ku, Tokyo, Japan

      Manufacturer Overview

      Sumitomo Heavy Industries, Ltd. (SHI) was established in 1888. SHI offers complete solutions for industrial machinery production and operations, heavy machinery for infrastructure, logistics, and construction, power generation systems as well as systems to reduce pollution, water purification, and ship construction. In addition, SHI also offers various software services including IT solutions.

    • Sensors Incorporated

      Manufacturer Overview

      Sensors Incorporated is a JHFOSTER company founded in 1977 in Kelsey Street, Delano, MN, as a manufacturer and supplier of equipment for industrial sensing, process control, barcode scanning, monitoring, and safety guarding. The company product line has automation sensors, machine systems, safety light curtains, plastic process control instruments, and safety sensors for workspace illumination, status indication, and personnel guidance. The company has products from brands such as Banner, Accurate Thermal Systems, Advanced Illumination, APG, and Baumer.

    • HARMONIC DRIVE SYSTEMS INC.

      Manufacturer Overview

      HARMONIC DRIVE SYSTEMS INC., founded n 1970 and based in Tokyo, Japan, is a manufacturer and seller of mechatronics products and speed reducer brands for incorporation in industrial robots, semiconductor manufacturing equipment, and other systems. The company offers a wide range of products including Harmonic Drive which is a speed reducer for precision control, Harmonic Gearhead for servo motor series, rotatory actuators, and linear actuators among others. The company serves various industries such as printing & bookbinding, robotics, medical equipment manufacturing, and many more. It has achieved the Japan Society for Design Engineering 50th Anniversary Award for Meritorious Achievement.

    • Top Gear Transmission Pvt Ltd
      • India Address: M-71, Addl. M.I.D.C. SATARA. Dist : Satara Maharashtra, India

      Company Overview

      Top Gear Transmission Pvt Ltd founded in Satara, Maharashtra, India, in 2000, is a manufacturer and distributor of transmission and material handling products. The company manufactures products including planetary mill drives, helical gearboxes, geared motors, winches, and hoist drives. Its auxiliary gearboxes are used between the engine and axle of the wheel for power transmission in mobile hydra cranes. The company has a manufacturing facility and warehouse of 13,000 square meters. It has received the National Udyog Ratna Award.

    • PARKER HANNIFIN CORP

      Company Overview

      Parker Hannifin Corporation was founded in 1917 and is headquartered in Cleveland, Ohio. Parker Hannifin is a manufacturer and distributor of motion and control technologies and systems for markets including mobile, industrial, and aerospace. Parker-Hannifin operates through two segments: diversified industrial and aerospace systems. Diversified industrial offers sealing, shielding, thermal products and systems, adhesives, diagnostics solutions, and hydraulic, pneumatic, and elctromechanical components and systems or industrial machinery and equipment. The aerospace segment offers control actuation systems and components, engine exhaust nozzles and assemblies, pilot controls, as well as others.

    • TOAMEC Co., Ltd.
      • Japan Address: NMF Shiba Bldg. 2F, 4-2-3 Shiba, Minato-Ku, Tokyo, Japan

      Distributor Overview

      TOAMEC Co., Ltd., founded in 1951 and based in Tokyo, Japan, distributor specializing in household appliances, electrical and electronic goods, and a range of industrial components. Its product line includes dynamic drives for machinery control, motor gears for torque transmission, hydraulic electronic controls for hydraulic system management, sending wind equipment for air flow control, and test equipment for performance assessment. Its products plays a vital role in the distribution of various equipment and components.

    • AutomationDirect Inc.

      Distributor Overview

      AutomationDirect.com was founded in 1994 to provide solutions for the industrial automation market and has been growing its list of offerings ever since. AutomationDirects’ extensive catalog includes individual components such as cables, various controls, I/O devices, relays, gauges, fittings, and sensors to complete systems. Many parts and devices, especially PLC units are customizable. AutomationDirect.com also provides support via video instructions, online manuals, a learning library, an active community forum to further assist customers.

Servo Motor Reduction Drive Manufacturer Ranking

*Including some distributors, etc.

Derivation Method

The ranking is calculated based on the click share within the servo motor reduction drive page as of November 2024. Click share is defined as the total number of clicks for all companies during the period divided by the number of clicks for each company.

Number of Employees

  1. Mitsubishi Electric Corporation: 145,696
  2. Sumitomo Heavy Industries, Ltd.: 24,584
  3. Tsubakimoto Chain Co.: 8,691

Newly Established Company

  1. Apex Dynamics Japan Co., Ltd.: 2005 (19 years ago)
  2. Top Gear Transmission Pvt Ltd: 2000 (24 years ago)
  3. SESAME MOTOR CORP.: 1990 (34 years ago)

Company with a History

  1. Tsubakimoto Chain Co.: 1917 (107 years ago)
  2. Mitsubishi Electric Corporation: 1921 (103 years ago)
  3. Matex Co., Ltd.: 1921 (103 years ago)

Servo Motor Reduction Drive Manufacturers in United States

*Including some distributors, etc.

Global Distribution of Servo Motor Reduction Drive Manufacturers by Country

*Including some distributors, etc.

Country Number of Companies Share (%)
Japan Japan 11 52.4%
United States of America United States of America 5 23.8%
Taiwan Taiwan 2 9.5%
China China 1 4.8%
Germany Germany 1 4.8%
India India 1 4.8%

List of Servo Motor Reduction Drive Products

11 products are listed.

Low backlash planet gear deceleration machine CP Alpha Basic-Wittenstein

Wittenstein

Low backlash planet gear deceleration machine CP Alpha Basic

40+ people viewing

■ In order to actually apply a reliable servo deceleration machine, the highest accuracy, dynamics, and average density over average are essential....


1 model listed

Standard type deceler AB series-Apex Dynamics Japan Co., Ltd.

Apex Dynamics Japan Co., Ltd.

Standard type deceler AB series

30+ people viewing

■ Characteristics ・ Output shaft ball bearing / straight type ・ There is a deceleration ratio of 21 types 21 types (3 to 100). * AB220 is a taper...


10 models listed
