This section provides an overview for poe switching hubs as well as their applications and principles. Also, please take a look at the list of 23 poe switching hub manufacturers and their company rankings. Here are the top-ranked poe switching hub companies as of December, 2024: 1.CONTEC Co., Ltd., 2.Optical Network Video Technologies Co., Ltd, 3.Wuhan Maiwe Communication Co., Ltd..
Table of Contents
Engaged in research on nitride semiconductor growth using the MBE method at Waseda University Graduate School. After graduating from graduate school in 2016, he joined a non-ferrous metal manufacturer.
Engaged in equipment maintenance and engineering work at metal smelting plants. Moved to a chemical manufacturer in 2022. Engaging in similar tasks.
A PoE switching hub is a switching hub with the ability to supply power through its Ethernet ports.
PoE stands for "Power over Ethernet" and refers to the ability to supply power to powered devices via Ethernet cables (so-called LAN cables), and is used by connecting devices that support the POE standard to each other via Ethernet cables.
A switching hub is a device that efficiently relays a network when multiple computers communicate with each other, using the Ethernet communication standard and relaying computer traffic through an Ethernet port.
Switching hubs were introduced in the 1990s. At that time, 10 Gbps was the typical network speed, but today, the speed has increased to 100 Gbps or even higher, and switching hubs are now available that support this speed.
PoE switching hubs are used on networks with Ethernet communications. The following is an example of a device connected to a PoE switching hub:
PoE-compliant receiver devices are suitable for devices located in remote areas because they do not require power cables. Therefore, they are often used for surveillance cameras and the like.
Note, however, that different POE switching hubs have different specifications in terms of the number of devices that can be powered and power supply capacity.
A PoE switching hub is a device that has both POE and switching hub functions. The respective functions are as follows:
The PoE function is a function that uses LAN cable wiring to supply power; a LAN cable is a group of two 4-pair thin core cables.
For communications at 100 Mbps or lower, only two pairs are used, one for transmitting and the other for receiving, but for communications at 1 Gbps or higher, all four pairs are used. There are two types of power supply methods: TypeA and TypeB.
Type A is a method in which the communication line and power supply line are shared, and is used for communications at 1 Gbps or faster, while Type B is a method in which power is supplied using two pairs, which are not used for communications at 100 Mbps or slower.
A switching hub is a feature that efficiently relays Ethernet communications. Although just a hub also has a relay function, it has the characteristic of retransmitting incoming communication data to all connected devices.
This has the disadvantage that the network tends to become congested because the data reaches other devices than the one it is communicating with. In contrast, switching hubs use MAC addresses, which are unique addresses of devices, to identify the devices with which they should communicate. Since data is sent only to the necessary devices, signals can be relayed efficiently.
PoE was defined as a standard by the Institute of Electrical and Electronics Engineers (IEEE), an American standards organization. The standardization of PoE enables connection even when the manufacturers of the devices receiving and receiving power are different from each other.
IEEE802.3af is a slightly older standard, and IEEE802.3at was developed to support a higher power output. Recently, PoE switching hubs are increasingly supporting PoE+.
PoE is divided into classes from 0 to 8 according to the power supplied, and the larger the class, the higher the power supply capacity. The larger the class, the higher the power supply capacity. The largest class, Class 8, is defined as 90 W for power supply and 73 W for power reception.
A PoE switching hub that supports PoE power receiving is available. This product can transmit power from a PoE powered device to a PoE powered device. This function is called pass-through.
Normally, the maximum distance for PoE is defined as 100 m, but pass through makes it possible to achieve a total transmission distance of 200 m. This function is useful in large factories.
When using pass-through, it is necessary to design the system so that the maximum total power is not exceeded; the amount of power available for PoE is not large, so connecting numerous devices to a PoE switching hub can easily exceed the maximum amount of power.
*Including some distributors, etc.
Sort by Features
Sort by Area
Patton Electronics Co., a manufacturer incorporated in 1984 and headquartered in Gaithersburg, Maryland, USA, specializes in UC, cloud, and IoT-enabling solutions for carrier, enterprise, and industrial networks. The extensive product range includes VoIP gateways, eSBCs, Ethernet extenders, and interface converters. These offerings serve diverse applications like business VoIP, cloud telephony, video conferencing, IoT, and industrial automation. To connect with local-market requirements, Patton operates training and support centers in Switzerland, Hungary, Lebanon, India, Vietnam, and the USA.
Omnitron Systems Technology, Inc. established in 1992 and based in Irvine, California, USA, is a manufacturer and distributor of fiber optic connectivity products. The company's product range includes media converters, network interface devices (NIDs), ethernet switches, power-over Ethernet media converters, and multiplexers. These products play a crucial role in facilitating the delivery of next-generation network services and are vital in both local area networks (LAN) and wide area networks (WAN). Serving industries like telecommunications, data centers, government agencies, and utilities, its offerings ensure efficient and ideal fiber connectivity.
Cisco Systems, Inc., founded in 1984 and based in San Jose, California, is a manufacturer, distributor, and supplier of networking hardware, software, and services. Their offerings include routers for network connection and traffic routing, switches to manage internal network traffic, wireless access points for wireless connectivity, security appliances to safeguard against unauthorized access and attacks, and collaboration solutions to facilitate communication and collaboration among individuals. Cisco's comprehensive range of products caters to diverse networking needs, enabling seamless communication, data transfer, and collaboration across networks.
NETGEAR is based in San Jose, California, USA, and is a manufacturer and distributor of networking and wireless products established in 1996 before its acquisition by Bay Networks in 1998. The company offers its Nighthawk branded performance WiFi routers for gaming or streaming applications, its Meural branded digital canvas for displaying photos or art pieces, and its Orbi branded mesh WiF system for supporting home networks. It also offers 5G mobile routers, cable modems, and ProAV switches. The company is OHSAS 18001-certified, and mainly serves the residential, commercial, and smart home sectors.
Maiwe Communication, established in 2001 and headquartered in Wuhan, China, is a manufacturer specializing in industrial internet communication devices. The company's product portfolio includes layer 2 rackmount unmanaged Ethernet switches, serial isolaters and repeaters, industrial network management software, embedded VDSL Ethernet extenders, wireless AP/access controllers, and more. These products find applications in various industry solutions, including rail transit, smart cities, the state grid, oil mining, and industrial automation. Its products have earned international certifications, such as CE, FCC, and RoHS.
Moxa Inc., founded in Brea, CA, in 1987 is a manufacturer of industrial connectivity products hat enable devices to connect, communicate, and collaborate with systems. The company's product portfolio includes, Ethernet Switches, Secure Routers, Wireless AP/Bridge/Client, Cellular Gateways/Routers and Ethernet Media Converters. The company serves markets including Automotive and Electric Vehicles, Renewable Energy and Energy Storage and Electronics and IT Infrastructure. They also provide services including product selection, installation, preventative maintenance, troubleshooting, and repair.
HIRAKAWA HEWTECH CORP., founded in 1948 and headquartered in Tokyo, Japan, is a manufacturer and supplier specializing in cables, electronic equipment, and medical equipment. The company's product portfolio includes high-speed cables, factory automation cables, optical converters, network equipment, and medical tubing. These products are utilized by various industries, including electronics, digital technology, information communication, broadcasting, and the medical sector. The company is ISO 14001 and ISO 9001 certified, with overseas subsidiaries in America, Mexico, Thailand, the Philippines, and Taiwan.
Dahua Technology Co., Ltd., established in 2001 and located in Hangzhou, China, is a manufacturer of video surveillance equipment manufacturing, specializing in video-centric AIoT solutions and services. The company offers a wide range of products, including network and HDCVI cameras, recorders and NVRs, and accessories. It also offers access control, video intercom, and video management system/software. Its product offers card readers and biometric readers to ensure secure premises at all times. The company has achieved the ISO/IEC 27701 certificate from the British Standards Institution. It serves various industries such as retail, banking and finance, education, healthcare, and more.
CONTEC is a manufacturer and developer of industrial computers founded in 1975 in Osaka, Japan as a subsidiary of Daifuku Co., Ltd. The company produces IoT devices, solutions, and components used in infrastructure, energy, medical care, and factory automation. Some of the company's products include M2M gateways and controllers for data collection, I/O modules for direct or remote control, industrial motherboards for performance reliability, and networking solutions like switching hubs for data communication. These supply clients companies like Hitachi, Mouser Electronics, and Acal BFi.
StarTech.com Ltd. (STC) is a Canadian manufacturer of IT connectivity products that was established in London, Ontario in 1985. The company produces hard drive enclosures, docking stations, and display adapters, as well as various cables using different connector standards. These are used to provide connectivity between computers, smart devices, and peripherals in home and company offices. STC products are mainly used by clients in information technology, education, and multimedia editing or production
Fiberroad Technology Co. Ltd., established in 2005 with headquarters in Shenzhen, Guangdong, China, is a manufacturer of industrial communication and networking devices. The company offers an extensive range of PoE switches, fiber conversion switches, and smart IoT surveillance boxes that provide data connectivity solutions between copper and fiber, including hardware for wireless network infrastructure. Its IIoT solutions cover industrial IoT management, inter-data centers, and utility-scale fiber optic transmission. The company's success stories include being an equipment provider for the Smart Urban Utility Tunnel pilot cities in China and an established FTTD (fiber to the desktop) provider.
Phoenix Contact is headquartered in Blomberg, Germany, originally founded in 1923. Phoenix Contact’s Israeli subsidiary was founded in 2006 and located in Quadima Tzoran. Phoenix Contact provides tools and components for e-mobility, power, infrastructure, process industry, production manufacturing, system manufacturing, and others. Phoenix Contact’s product lines include automate including cloud computing, connect including PCB terminal blocks, “mark, assemble, and install” including hand tools, “supply, charge, and protect” including power distributors, and “switch, measure, and monitor” including relays and optocouplers.
CTC Union Technologies Co. Ltd, established in 1993 and based in Taiwan, China, is a manufacturer and supplier of networking solutions and products. Its product portfolio includes management software, rackmount switches, ethernet switches, media converter, cellular routers, and fiber multiplexers. They are mainly used in two industries including the digital and telecommunication sectors. The company also offers a warranty policy, quality assurance with certified products, environmentally friendly solutions, and customer service.
Perle Systems, founded in 1976 and based in Princeton, NJ, USA, is a manufacturer and supplier of device networking and Internet of Things (IoT) connectivity hardware. The company's product range includes IRG 5G / LTE Routers, Industrial Switches, Console Servers, and Fiber Media Converters. These products establish network connectivity, securely transmit information, and remotely control IT equipment. They primarily serve industries such as telecommunications, manufacturing, and information technology. In addition to its product offerings, it provides setup, technical support, and equipment management services.
Panasonic Electric Works Networks Co. Ltd., established in 1989 and based in Tokyo, Japan, is a manufacturer of network equipment. The company offers comprehensive support for designing spatial infrastructure, encompassing information networks, electricity, and interiors. Its product range includes L3 switches, edge switches, and wireless access points. It proposes total network construction and security systems centered on switching hubs, providing end-to-end support from designing, maintenance, and post-implementation support for multi-vendors.
Computer Network Accessories Inc., based in Dayton, Ohio, is an online supplier of several electronic products, such as power adapters, network hardware, and bulk cabling. The company also stocks computer hardware and accessories like keyboards, hard drives, and modems and sells toner cartridges compatible with several brands like HP, IBM, and Epson. The company has an online catalog of its products where customers can make orders, and it allows purchase orders. It provides free shipping for all orders over $99, and customers can return goods if unsatisfied within 30 days of purchase.
3onedata Co., Ltd., founded in China in 2001, is a supplier of IIoT products and industrial communication solutions. The company offers a range of IIoT edge devices for collecting and transmitting data from industrial machinery and equipment, IIoT gateway devices that bridge the gap between field devices and the cloud, enabling seamless data transmission, IIoT cloud platform for data storage, analytics, and remote monitoring and tailored IIoT solutions to meet specific industrial needs.
Ranking as of December 2024
Derivation Method| Rank | Company | Click Share |
|---|---|---|
| 1 | CONTEC Co., Ltd. |
13.5%
|
| 2 | Optical Network Video Technologies Co., Ltd |
9.5%
|
| 3 | Wuhan Maiwe Communication Co., Ltd. |
9.5%
|
| 4 | Panasonic Electric Works Networks Co., Ltd. |
9.5%
|
| 5 | HIRAKAWA HEWTECH CORP. |
9.5%
|
| 6 | NADDOD Pte. Ltd. |
8.1%
|
| 7 | Mahanet.CO.LTD |
6.8%
|
| 8 | Moxa Inc. |
5.4%
|
| 9 | 3onedata Co., Ltd |
4.1%
|
| 10 | Shenzhen Ewind Technology Co.,Ltd |
4.1%
|
Derivation Method
The ranking is calculated based on the click share within the poe switching hub page as of December 2024. Click share is defined as the total number of clicks for all companies during the period divided by the number of clicks for each company.Number of Employees
Newly Established Company
Company with a History
*Including some distributors, etc.
*Including some distributors, etc.
| Country | Number of Companies | Share (%) |
|---|---|---|
|
United States of America
|
4 | 23.5% |
|
Japan
|
4 | 23.5% |
|
China
|
4 | 23.5% |
| taiwa | 1 | 5.9% |
|
Germany
|
1 | 5.9% |
|
Taiwan
|
1 | 5.9% |
Canada
|
1 | 5.9% |
Singapore
|
1 | 5.9% |
129 products found
129 products
BlackBear TechHive Japan Co., Ltd.
260+ people viewing
Last viewed: 13 hours ago
Very Fast Response
■Features Entry level unmanaged switch. Entry-level unmanaged switches developed by ATOP provide a reliable, robust, and low-cost solution for simp...
4 models listed
BlackBear TechHive Japan Co., Ltd.
390+ people viewing
Last viewed: 9 hours ago
Very Fast Response
■Features Entry level unmanaged switch. Entry-level unmanaged switches developed by ATOP provide a reliable, robust, and low-cost solution for simp...
8 models listed
CASO Co., Ltd.
50+ people viewing
Last viewed: 16 hours ago
Fast Response
9 models listed
BlackBear TechHive Japan Co., Ltd.
200+ people viewing
Last viewed: 16 hours ago
Very Fast Response
■Features Entry level unmanaged switch. Entry-level unmanaged switches developed by ATOP provide a reliable, robust, and low-cost solution for simp...
6 models listed
BlackBear TechHive Japan Co., Ltd.
180+ people viewing
Last viewed: 1 day ago
Very Fast Response
■Features Lite Managed Smart Secure Switch. ATOP's Light Managed Smart Secure Switch is a cost-effective solution that provides low-latency network...
2 models listed
BlackBear TechHive Japan Co., Ltd.
260+ people viewing
Last viewed: 1 day ago
Very Fast Response
Low profile Lite managed switch. The EH3408 series is a Fast Ethernet Lite managed switch that saves space and costs. It is equipped with settings ...
4 models listed
20+ people viewing
■Use example Due to a series of incidents on trains, the Ministry of Land, Infrastructure, Transport and Tourism is making it mandatory to install ...
BlackBear TechHive Japan Co., Ltd.
300+ people viewing
Last viewed: 1 day ago
Very Fast Response
■Features Unmanaged switch with EMC (electromagnetic compatibility). ATOP's unmanaged switches with plug-and-play Gigabit connectivity comply with ...
6 models listed
20+ people viewing
Last viewed: 9 hours ago
■Industrial PoE switching hub compliant with IEEE802.3af standard DEH-GTX14AF is a gigabit type PoE switching hub with 14 ports. 12 out of 14 ports...
BlackBear TechHive Japan Co., Ltd.
340+ people viewing
Last viewed: 1 day ago
Very Fast Response
■Features Unmanaged switch with PoE boost function for harsh environments. This is a product that adds PoE boost function to a switch that is suita...
9 models listed
20+ people viewing
Last viewed: 1 day ago
■Equipped with 8 PoE ports + 2 uplink ports, realizing large capacity power supply and space saving ・DEH-GP10C is a gigabit type industrial PoE sw...
Zexelon Co., Ltd.
80+ people viewing
Last viewed: 1 day ago
■Features ・1000BASE-T (Gigabit) compatible. ・Supports up to 120W power supply. (IEEE802.3af/at standard compliant) - Equipped with PD Alive (conn...
BlackBear TechHive Japan Co., Ltd.
330+ people viewing
Last viewed: 22 hours ago
Very Fast Response
■Features Lite managed smart switch with 24V PoE boost function. A switch that combines a compact size with a housing that is sufficiently resistan...
8 models listed
10+ people viewing
Last viewed: 1 day ago
■Built-in booster circuit allows use of DC24V/DC48V power supply ・DEH-GP8V2 is an industrial PoE switching hub that supports a wide range of input...
10+ people viewing
■EN61373:2010 compatible EN 61373:2010 is a vibration and shock test standard for railway vehicles and their equipment. Designed for use in harsh e...
Kanematsu Sustech Co., Ltd.
30+ people viewing
Last viewed: 4 hours ago
BlackBear TechHive Japan Co., Ltd.
260+ people viewing
Last viewed: 3 hours ago
Very Fast Response
Lite managed switch with NAT function.
4 models listed
20+ people viewing
Last viewed: 1 day ago
■Built-in booster circuit allows use of DC12V/DC24V/DC48V power supply - Compatible with DC12V, allowing PoE devices to be installed in a wide rang...
BlackBear TechHive Japan Co., Ltd.
320+ people viewing
Last viewed: 1 day ago
Very Fast Response
■Features Industrial PoE managed Layer-2 switch. ATOP's managed Layer-2 switches for harsh environments provide a robust and reliable solution for ...
10 models listed
BlackBear TechHive Japan Co., Ltd.
400+ people viewing
Last viewed: 6 hours ago
Very Fast Response
■Features Industrial PoE managed Layer-2 switch. ATOP's managed Layer-2 switches for harsh environments provide a robust and reliable solution for ...
9 models listed
BlackBear TechHive Japan Co., Ltd.
420+ people viewing
Last viewed: 1 day ago
Very Fast Response
■Features Industrial PoE managed Layer-2 switch. ATOP's managed Layer-2 switches for harsh environments provide a robust and reliable solution for ...
10 models listed
