This section provides an overview for hydraulic torque wrenches as well as their applications and principles. Also, please take a look at the list of 22 hydraulic torque wrench manufacturers and their company rankings. Here are the top-ranked hydraulic torque wrench companies as of December, 2024: 1.FASTORQ, 2.Shingare Industries, 3.Torq/Lite.
Table of Contents
Categories Related to Hydraulic Torque Wrenches
A hydraulic torque wrench is a torque wrench that can apply large force powered by hydraulic pressure.
Hydraulic torque wrench is mainly used for fastening large bolts because it can generate large torque with a small force.
Hydraulic torque wrench consists of three major parts.
The hydraulic pump can also be used in explosion-proof areas by using an air hydraulic pump.
Hydraulic torque wrenches are used in the following situations where medium to large bolts and nuts need to be tightened or loosened.
Shield tunneling, among others, takes advantage of the benefits of hydraulics, which can be used even when the power source is far away. The use of long hydraulic hoses makes it possible to tighten bolts underwater and flange bolts of submarine cables.
Hydraulic torque wrench uses "Pascal's Principle" which can generate large torque with a small force using hydraulic pressure.
Pascal's principle is a law that states that when a certain amount of force is applied to a sealed container of liquid, the pressure is equal in all directions without decreasing the volume.
For example, suppose the pressure and cross-sectional area applied to a container are as follows
In this case, the following torque is required to maintain the same pressure.
Thus, since a large output can be obtained with a small input, a hydraulic torque wrench is used for automobile brakes and hydraulic jacks, as well as a hydraulic torque wrench.
Hydraulic torque wrench makes it easy to tighten bolts and nuts.
At this time, the ratchet does not rotate to the specified torque in a single stroke but rotates approximately 30 degrees in each stroke. In addition, the ratchet mechanism includes a reaction plate, which moves only in one direction. Therefore, the bolt does not reverse when the piston returns.
These are the advantages of using a hydraulic torque wrench. In particular, the low noise level during operation is a unique advantage of the hydraulic torque wrench. For example, when you want to excavate a tunnel at night on the ground, you are less likely to disturb the neighbors.
However, the hydraulic torque wrench has the disadvantage of slow working speed. However, it is possible to reduce the working time by connecting two units.
A torque conversion table is often enclosed with the hydraulic torque wrench. If you do not have it, there are websites where you can convert units on the web.
Tightening is complete when the pressure rises to the set value but the ratchet does not turn. Insufficient tightening can cause accidents or injuries, so be sure to check the tightening.
*Including some distributors, etc.
Sort by Features
Sort by Area
TRITORC, Inc. established in 1994 and based in Pasadena, Texas, is a manufacturer and supplier of hydraulic, pneumatic, electric, and manual torque wrenches. The company's product range includes hydraulic torque wrenches, bolt tensioners, heavy-duty impact sockets, manual torque multipliers, and pipe-cutting tools. These tools are pivotal for robust bolting, machine adjustments, and intricate cutting tasks. Serving industries such as machinery manufacturing, bolting services, industrial maintenance, and on-site machining. its services include bolting solutions, in situ machining solutions, hot tapping and line stopping, and re-tubing.
Snap-on Incorporated, founded in 1920, is an American designer, manufacturer and marketer of high-end tools and equipment for professional use in multiple industries. The company’s product lines include hand tools, power tools, automotive diagnostics and shop equipment, automotive diagnostics software and other solutions for the transportation service, industrial, government, education, agricultural, and other commercial applications. Products are sold through its franchise dealer van, company direct sales and distributor and Internet channels. Now, it is a $3.7+ billion S&P 500 company headquartered in Kenosha, Wisconsin and employs approximately 12,200 people worldwide.
TorcUP, established in 1996 and based in Pennsylvania, USA, is a manufacturer of industrial torque wrenches and bolting tools. The company offers a range of tools, including hydraulic, pneumatic, electric wrenches, and hydraulic pumps, along with complementary products such as turbine tooling, impact sockets, and multi-purpose tools. It also provides tooling for rental and rent-to-own in selected locations, along with full repair and refurbishment services for all TorcUP models. The company is ISO/IEC 17025:2017 certified, with a global network of representatives, distributors, calibration centers, and staff to offer technical support across North America, Asia, Africa, Australia, and Europe.
Powermaster Engineers Pvt. Ltd. is an Indian manufacturer of tube expanders, tube cleaners, pipe beveling machines, and other tube processing equipment. The company was founded in 1972 and is headquartered in Khairne, Navi Mumbai. Its main activity is designing, developing, and manufacturing tube processing equipment such as tube tools, bolting tools and spring balancers. The company also offers a wide range of bolting services, such as controlled bolting, hot bolting, in-situ machining, re-tubing and repairs, and calibration. Powermaster's products are used by many customers, including the automotive, aerospace, and oil and gas industries.
TorcStark, established in 2000 and based in Dezhou City, Shandong, China, is a manufacturer of hydraulic torque wrenches. The company also produces other products, such as hydraulic wrench pumps, automatic wrench pumps, hydraulic pullers, and 3D adjustment systems, while offering solutions for tightening or loosening the bolts and moving and positioning projects. All of its products are used in bridges, oil fields, subways, and installation and maintenance of wind farms. The products manufactured are used in 170 wind farms across China and hold quality management system certificates to abide by the standards while manufacturing.
Larzep is based in Guipúzcoa, Spain, and is a manufacturer of hydraulic equipment for high pressure applications that was established in 1940 as a part of the Mondragón group of companies. The company’s product lineup includes electric, air, and hydrotest pumps for powering hydraulic tools or cylinders. It also offers cylinders and jacks for high-force operations such as lifting or bending, presses for forming or straightening operations, and spreaders for aligning flanges or doors. The company chiefly serves client’s in Europe’s construction, mining, and energy industries.
FPT Fluid Power Technology S.r.l., established in 1966 and headquartered in Genoa, Italy, is a manufacturer of high-pressure hydraulic equipment from 700 to 4,000 bar. The company's products include lifting, bolting, and tensioning systems. It also offers both standard and custom-made products according to customer specifications. It has the latest generation of CNC machines for turning and milling to manufacture all components that are assembled and tested. The company has a quality management system certificate ISO 9001:2008. It serves various industries such as construction, mining, oil and gas, shipbuilding, and more.
alki Technik GmbH, founded in 1984 and based in Ingolstadt, Germany, is an ISO 9001 certified manufacturer of screwdriving tools under the alkitronic brand. Its product range includes pneumatic, battery-operated, and electric screwing systems used in a wide range of industries such as agriculture, wind power, and steel construction. In 1987, the company developed the pneumatic torque multiplier, and in 1992, it expanded its product portfolio to include hydraulic and inspection tools. The first branch was opened in France in 1995, and in 2001, the company developed the electric torque multiplier with a synchronous motor.
Hangzhou WREN Hydraulic Equipment Manufacture Co., Ltd., founded in 1992, is a manufacturer of hydraulic tool and equipment based in China. The company's products are widely sold to Europe and the United States, the Middle East and southeast Asia and other markets. Its main hydraulic wrench products are now one of the world's top few hydraulic wrench product series. It provides its products through the TuV company TuV certification, realizing the hydraulic wrench large-scale production, with an annual production capacity of 10000 sets. It diversified its sales model, and also launched a series of preferential measures to benefit its customers.
Powerjac Systems Pvt.Ltd., founded in Karnataka, India, in 2002 is a manufacturer of oil hydraulics, lightweight- heavy-duty jacks, and cylinders, systems. The company's product portfolio includes hydraulic pumps and motors, used to deliver optimal power and control in hydraulic circuits, hydraulic valves, including directional control valves, pressure control valves and hydraulic cylinders. The company serves markets including Medical and Healthcare, Aerospace and Defense, Consumer Goods, Industrial Manufacturing and Construction and Building.
BOLTORQ was founded in 2014 and is based in Jamnagar, Gujarat, India, as a manufacturer and marketer of bolt tightening equipment. The company's product portfolio comprises electric torque wrenches, nut splitters, shear wrenches, and hydraulic torque wrenches, among others. The products serve various industries, offering specialized solutions for different applications, from precise torque control in assembly lines to removing stubborn nuts during maintenance and ensuring accurate bolt tightening in structural steelwork. The company caters to various industries, including automotive, aerospace, construction, manufacturing, and petrochemical.
Shingare Industries, established in 2018, based in Mumbai, Maharashtra, India, is a manufacturer of engineering products. The company is a supplier of condenser tube expanders, stube installation tools, tube expansion systems, tube pulling machines, and high pressure jet cleaners, among others. Their services include in situ machining solutions, bolting solutions, and tube cleaning machines. The company exports their products to more than 65 countries all over the globe. The company contact modes are by mail, phone, and physical address.
RIVERLAKE, established in 2005, based in Taizhou, China, is a manufacturer and supplier of high-force hydraulic tools. The company manufactures a wide range of hydraulic cylinders, pumps, bolting tools, flange maintenance tools, pullers, and other hydraulic tools. Their products and services are used in projects including bridge construction, highway, pipeline construction, railway construction, and heavy lifting, among others. The company has provided services to over 2000 industrial and mining companies. The company employs well-trained engineers and sales representatives who provide excellent customer service and tools.
ITH Bolting Technology headquartered in Meschede, Germany is a manufacturer and system supplier of bolting technology that distributes industrial bolting, torque wrenches, and tensioning tools solutions. The company’s bolting tool portfolio contains hydraulic bolt tensioning cylinders and hydraulic torque wrenches. They also offer bolting solutions for tightening and loosening industrial bolt connections from M16 (3/8’') and up. Additionally, they offer tension and torque tool rental. Their products are used in various industries such as wind energy, oil and gas, power generation, mining, and shipbuilding.
Enerpac, since 1910, has been a manufacturer of advanced industrial tools and a service provider located in MenomoneeFalls, Wisconsin, USA. The company produces power units, machine moving tools, pipe blenders, tension meters, and load cells. It also created cutters, gantries, presses, cylinders, and strand jacks used in aerospace, bridges, automotive, mining, and power generation industries. The firm offers rental products, training, hydraulic education, and services such as bolting, tool crib inspection, and calibration. It has 8 manufacturing facilities in The Netherlands, USA, Spain, UK, China, and India.
Carl Stahl Hebetechnik GmbH is a manufacturer of lifting and load suspension equipment that was originally founded in 1880 as a rope-making facility in Süßen, Baden-Württemberg, Germany. The company primarily produces specialized lifting equipment such as application-specific ropes, tripod or workshop cranes, and series hoists. It also offers stainless steel accessories, load restraint systems, and industrial-grade personal protective equipment. The company chiefly serves clients in the food and beverage, construction, and logistics industries.
Momento AB is an ISO 9001-certified manufacturer of machine-operated sockets and related accessories that was established in Nyköping, Sweden, in 1951. The company’s product lineup includes bolting tools for providing precise tightening or loosening of bolts or nuts, and impact sockets for providing high torque transmission for power tools or machines. It also offers hydraulic power tools for bolting operations, and heat treatment services for customer projects. The company primarily serves its clients in Europe’s industrial manufacturing, automotive assembly, and oil and gas drilling sectors.
TorqLite, established in 1981 and headquartered in Houston, TX, United States, is a hydraulic torque wrenches and related tools manufacturer. The company's products include low-clearance bolting tools, hydraulic pump power consoles, and high-speed battery-powered multipliers. These tools are used in construction, mining, and industrial process plants, and the company primarily serves original equipment manufacturers and private label clients. Its services include the provision of extended warranty programs and a riser tool repair and maintenance program.
Hongli Pipe Machinery, founded in 1986 in Hangzhou, Zhejiang Province, China, is a manufacturer of pipe threading machines, grooving machines, pipe cutting machines, and other pipe-related equipment. These machines improve efficiency and precision in various pipe-related tasks, such as threading, grooving, and cutting. The products are equipped with durability, accuracy, and ease of use and are essential tools for professionals in the plumbing, construction, and pipeline industries. The company distributes products not only in China but also in international markets, as a provider of optimal-quality pipe machinery solutions. It has obtained ISO, CE, SGS, and BIS certifications.
Maschinenfabrik Wagner GmbH & Co. KG, founded in 1962 and based in Much, Germany, is a manufacturer and supplier of bolting technology equipment. The company's product range includes battery nutrunners, electric nutrunners, pneumatic nutrunners, hydraulic torque wrenches, and tensioners. These products are designed for secure fastening, precise torque application, and efficient tensioning. The company primarily serves the wind energy, energy & power plants, oil & gas, and traffic engineering industries. The company also offers services such as customer service, maintenance & repair, mobile maintenance service, and a rental business.
Hire Torque Ltd Group is a British supplier and distributor of controlled bolting as well as joining equipment established in 1996 and headquartered in Cramlington, Northumberland. The company’s product inventory includes lifting equipment, bolt tensioners for uniform bolt loading, and hydraulic splitters or nut cutters. It also offers bolting software, portable pipe cutting machines, and a wide selection of ENERPAC brand tools. Aside from marketing products, the company also provides maintenance and repair, engineering, calibration services. It primarily serves clients in the oil and gas, wind energy, and petrochemical industries.
Ranking as of December 2024
Derivation Method| Rank | Company | Click Share |
|---|---|---|
| 1 | FASTORQ |
9.9%
|
| 2 | Shingare Industries |
6.4%
|
| 3 | Torq/Lite |
6.3%
|
| 4 | Hongli Pipe Machinery |
5.8%
|
| 5 | WREN |
5.7%
|
| 6 | BOLTORQ |
5.4%
|
| 7 | RIVERLAKE |
5.4%
|
| 8 | Powerjac Systems Pvt.Ltd. |
5.3%
|
| 9 | TorcUP |
5.3%
|
| 10 | FPT Fluid Power Technology S.r.l. |
4.9%
|
Derivation Method
The ranking is calculated based on the click share within the hydraulic torque wrench page as of December 2024. Click share is defined as the total number of clicks for all companies during the period divided by the number of clicks for each company.Number of Employees
Newly Established Company
Company with a History
*Including some distributors, etc.
*Including some distributors, etc.
| Country | Number of Companies | Share (%) |
|---|---|---|
|
United States of America
|
4 | 25.0% |
|
India
|
4 | 25.0% |
|
China
|
3 | 18.8% |
|
Germany
|
2 | 12.5% |
|
Spain
|
1 | 6.3% |
|
Italy
|
1 | 6.3% |
|
United Kingdom
|
1 | 6.3% |
177 products found
177 products
Japan Pralad Co., Ltd.
600+ people viewing
Last viewed: 12 hours ago
Standard Response
5.0 Company Review
■ Plalad's hydraulic torque wrench is an ultra -precision spline gear and 9 -drive claw structure that does not bite gear. The number of ratchet te...
10 models listed
Japan Pralad Co., Ltd.
8870+ people viewing
Last viewed: 4 hours ago
Standard Response
5.0 Company Review
Pralado is the industry's No. 1 safety design, the industry's only hydraulic torque wrench, the only industry's only patent SQS high -pressure safe...
6 models listed
Japan Pralad Co., Ltd.
320+ people viewing
Last viewed: 10 hours ago
Standard Response
5.0 Company Review
Pralado's hydraulic torque wrench is used in the construction of Tokyo Sky Tree, the construction of Abeno Harukas, the assembly of the world's lar...
4 models listed
Japan Pralad Co., Ltd.
500+ people viewing
Last viewed: 2 hours ago
Standard Response
5.0 Company Review
Pralado is the world's oldest history and traditions of hydraulic torqueken (SINCE1962). The design and manufacturing of all hydraulic torque wrenc...
10 models listed
Yunex joint company
320+ people viewing
Last viewed: 5 hours ago
Very Fast Response
This product comes with a two -year warranty regardless of the reason. MXTPLUS is a combination of the world's latest technology. This product is c...
4 models listed
Japan Pralad Co., Ltd.
560+ people viewing
Last viewed: 5 hours ago
Standard Response
5.0 Company Review
■ Hydraulic torqueen PL5VS tightening torque 550Nm to 5,500Nm. A lineup of 174 models of the center hall type. ■ Plalad hydraulic torlen center ha...
10 models listed
Japan Pralad Co., Ltd.
290+ people viewing
Last viewed: 2 hours ago
Standard Response
5.0 Company Review
Hydraulic torlenen PL8VS tightening torque 800Nm to 8,000 nm. A lineup of 174 models of the center hall type. ■ Plalad's hydraulic torque wrench is...
3 models listed
Yunex joint company
550+ people viewing
Last viewed: 4 hours ago
Very Fast Response
The hydraulic torlenen Avanti series provides the maximum torque output with the maximum output of 180,000 nm or more for the largest model. The Av...
8 models listed
Bestma Co., Ltd.
320+ people viewing
Last viewed: 2 hours ago
Use by attaching an impact socket to the drive shaft. Tighten by taking a stable reaction force with a flange, etc. This is a standard wrench that ...
8 models listed
![Hydraulic torque wrench T-series [socket replacement type]-Titan Japan Co., Ltd.](https://metoree.s3.ap-northeast-1.amazonaws.com/img/products-new/3006316202410031.png)
Titan Japan Co., Ltd.
40+ people viewing
Last viewed: 2 hours ago
■Easily compatible with nuts of various sizes by replacing impact sockets Hydraulic torque wrench T-series is a socket-replaceable hydraulic torque...
Yunex joint company
490+ people viewing
Last viewed: 1 hour ago
Very Fast Response
MXT Series has more than 100,000 units worldwide. Since its launch in 1990, it has been demonstrated that it has excellent quality and durability i...
8 models listed
Japan Pralad Co., Ltd.
450+ people viewing
Last viewed: 6 hours ago
Standard Response
5.0 Company Review
Pralado is the world's oldest history and traditions of hydraulic torqueken (SINCE1962). The design and manufacturing of all hydraulic torque wrenc...
10 models listed
Bestma Co., Ltd.
240+ people viewing
Last viewed: 12 hours ago
This type allows the wrench body to be hung directly on the nut. Effective in places where there is no space above. It takes a stable reaction forc...
6 models listed
![Hydraulic torque wrench LP-series [Glasses type]-Titan Japan Co., Ltd.](https://metoree.s3.ap-northeast-1.amazonaws.com/img/products-new/3006316202410032.png)
Titan Japan Co., Ltd.
30+ people viewing
■Used by attaching directly to the nut. Effective even for work with height restrictions The hydraulic torque wrench LP-series is a direct insert t...
Japan Pralad Co., Ltd.
520+ people viewing
Last viewed: 1 hour ago
Standard Response
5.0 Company Review
Pralado's hydraulic torque wrench is used in the construction of Tokyo Sky Tree, the construction of Abeno Harukas, the assembly of the world's lar...
10 models listed
Yunex joint company
340+ people viewing
Last viewed: 5 hours ago
Very Fast Response
This product is the perfect product for torque values and reproducibility required. The simple design consisting of three parts was created by Hy...
6 models listed
Bestma Co., Ltd.
300+ people viewing
Last viewed: 1 day ago
This type allows the wrench body to be hung directly on the nut. Effective in places where there is no space above. It takes a stable reaction forc...
10 models listed
Yunex joint company
470+ people viewing
Last viewed: 6 hours ago
Very Fast Response
Stealth is the most advanced work pressure torque wrench for high -talk. Slim design fits everywhere and provides unparalleled speed and power. It ...
6 models listed
Japan Pralad Co., Ltd.
420+ people viewing
Last viewed: 2 hours ago
Standard Response
5.0 Company Review
Hydraulic torlenen PL30VS tightening torque 3,000 nm to 30,000 nm. A lineup of 174 models of the center hall type. ■ Pralado is the world's oldest ...
5 models listed
Bestma Co., Ltd.
160+ people viewing
Last viewed: 5 hours ago
BESTMA's original wrench was born from the needs of the field. This wrench was created using years of know-how for tightening universal joints and ...
Japan Pralad Co., Ltd.
450+ people viewing
Last viewed: 8 hours ago
Standard Response
5.0 Company Review
Hydraulic torlenen PL45VS tightening torque 4,500 nm to 45,000nm. A lineup of 174 models of the center hall type. ■ Plalad's hydraulic torque wren...
7 models listed
Yunex joint company
560+ people viewing
Last viewed: 11 hours ago
Very Fast Response
XLCT is the most major narrow work bolt tightening tool that has been delivered over 100,000 units worldwide. XLCT has proved quality and durabilit...
6 models listed
Bestma Co., Ltd.
170+ people viewing
Last viewed: 18 hours ago
BESTMA's original wrench was born from the needs of the field. This wrench was created using years of know-how for tightening universal joints and ...
Japan Pralad Co., Ltd.
390+ people viewing
Last viewed: 1 day ago
Standard Response
5.0 Company Review
■ A double -mobilized electric hydraulic pump for hydraulic torqueen. Voltage: 200V three phases, 230V single phase specifications. Maximum hydraul...
3 models listed
Japan Pralad Co., Ltd.
310+ people viewing
Last viewed: 13 hours ago
Standard Response
5.0 Company Review
■ The fastest automatic hydraulic pump in the world for hydraulic torqueen. This is the world's first development and commercialization of "complet...
3 models listed
Japan Pralad Co., Ltd.
440+ people viewing
Last viewed: 5 hours ago
Standard Response
5.0 Company Review
■ PE100CF-5 Product specifications ・ Double motion hydraulic pump for hydraulic torque wrench ・ Standard equipment for oil cooler ・ High low -vo...
Japan Pralad Co., Ltd.
340+ people viewing
Last viewed: 2 hours ago
Standard Response
5.0 Company Review
■ Hydraulic torlen center hall RE type Large torque wrench of super large bolt tightening tools. The world's largest tightening torque 150,000 nm. ...
3 models listed
Japan Pralad Co., Ltd.
300+ people viewing
Last viewed: 3 hours ago
Standard Response
5.0 Company Review
■ Hydraulic torque -type air -type hydraulic pump, maximum pressure 80MPa specification. ■ Air -type hydraulic turbo pump (explosion -proof air ty...
2 models listed
Yunex joint company
360+ people viewing
Last viewed: 1 day ago
Very Fast Response
This product, which was easy to operate, and was designed to be movable from three types of parts, was commercialized by Hytorc more than 30 years ...
5 models listed
Atlas Copco UK Holdings Ltd
30+ people viewing
Standard Response
Highly durable specifications for even the toughest work applications ■Summary Atlas Copco's Hydraulic Square Drive Wrench RT is robust, powerful ...
