  4. Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E (TOCHIGIYA CO.,LTD.)
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-TH-190E-4-0.3
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-TH-190E-2-1.0
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-TH-190E-2-2.0
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-TOCHIGIYA CO.,LTD.

Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E
TOCHIGIYA CO.,LTD.

About This Product

■Features

This is a conductive hinge that can be stopped at any desired position. It can be mounted on the back (inside) to avoid compromising the appearance of the enclosure. It allows for a wider opening angle compared to conventional products. It can be used horizontally or vertically.

■Applications

Fixtures (payment machines, charging machines), enclosures requiring a wide door opening angle, enclosures where door sagging is undesirable, enclosures requiring conductivity, enclosures where design is paramount and appearance should not be compromised.

■Specifications

Stud bolt length should be 8mm or less. This product can be used in combination with TH-191E-4. Do not adjust the torque (adjust the nut). Please also check the "Free-Stop Hinge Specifications".

■Precautions

The resistance value is for this product alone. While you can expect the "effect of not needing bonding wires" and the "effect of providing conductive support in case of wire breakage when used with bonding wires," please be sure to verify this in actual implementation before making a decision. Also, do not use it as an electrical component (lead wire, etc.). Since painted surfaces do not conduct electricity, please mask the area around the mounting holes when installing on a painted enclosure. The reference door weight is the value when using two hinges. This is for strength, not torque. This product is for indoor use only.

  • Product

    Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E

Share this product


40+ people viewing

Last viewed: 3 hours ago

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

3 Models of Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E

Click on the part number for more information about each product

Image Part Number Price (excluding tax)
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-Part Number-TH-190E-4-0.3

TH-190E-4-0.3

Available upon quote
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-Part Number-TH-190E-2-1.0

TH-190E-2-1.0

Available upon quote
Conductive Free-Stop Hinge (Reverse Hinge Type) TH-190E-Part Number-TH-190E-2-2.0

TH-190E-2-2.0

Available upon quote
