High-precision measurement rigid type 6-axis force/torque sensor FT-AXIA with a freedom of 6 ° axis
Sunk Japan Co., Ltd.
About This Product
Power/torque sensor
High -precision measurement rigid type 6 -axis force / torque sensor with a degree of freedom of 6 ° axis
Advantages and benefits
■ Compact design
By spacing setup with built -in electronic devices
■ Two types of comparison can be used
This allows you to manage two types of measurements through the web interface.
■ Plug and work
Establish direct compatibility with KUKA products and Universal Robots products by software modules
■ Low cost despite high accuracy
By optimized manufacturing
■ Robust specifications
Because the overload range due to protection against damage is high, even for short -term overload
■ LED display specification
Status display of sensor without evaluation through controller
Options, others
■ 6 -axis force/torque sensor
The strain meter (DMS) measures the strain on all of the six freedom (fx, fz, fz, mx, my, mz). The signal from the DMS is directly processed by the sensor and is provided as power and moment data through various communication protocols.
■ Sensor cable
The sensor cable connects the sensor to the control line through the 8-pin M12 connector via the M8 connector or M12 connector. Voltage and communication lines are integrated and protected with sensor cables. The sensor signal is protected from the electric field and machine load by the very adaptable sensor line.
■ Control line
The control line is a Y -shaped distribution cable and is connected to the sensor line with an M12 socket. The voltage is supplied to the sensor via the 3rd Pole Open, and the RJ-45 connector allows you to communicate with the sensor independently with Ethernet or Ethernet according to the version.
* There are other part numbers.
-
Product
High-precision measurement rigid type 6-axis force/torque sensor FT-AXIA with a freedom of 6 ° axis
-
Handling Company
Sunk Japan Co., Ltd.
10 Models of High-precision measurement rigid type 6-axis force/torque sensor FT-AXIA with a freedom of 6 ° axis
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Control line | Correct 1 | Correct 2 | D diameter (mm) | Height Z (mm) | Housing material | IP protection grade | Measurement range FX, fy (n) | Measurement range FZ (n) | Measurement range MX, My (NM) | Measurement range MZ (NM) | Overload FX, FY (N) | Overload FZ (N) | Overload MX, My (NM) | Overload MZ (NM) | Recommended frequency FX, FY, MZ (Hz) | Resolution FX, fy (n) | Resolution FZ (N) | Resolution MX, My (NM) | Resolution MZ (NM) | Resonate vibration number FZ, MX, My (Hz) | Sensor cable | Weight (kg) | evaluation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
FTN-AXIA80-Dual Si-75-4/Si-150-8 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-75-4 | Si-150-8 | 82 | 25.4 | aluminum | 64 | ± 75 | ± 235 | ± 4 | ± 4 | ± 2,350 | ± 7,500 | ± 40 | ± 40 | 1,500 | 0.04 | 0.04 | 0.002 | 0.002 | 1,500 | 4m, M8/M12 plug | 0.28 | Ethernet |
|
|
EOA-UR3510-FTN-AXIA 80 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-200-8 | Si-500-20 | 85 | 63.4 | aluminum | 64 | ± 200 | ± 360 | ± 8 | ± 8 | ± 2,500 | ± 4,500 | ± 100 | ± 100 | 2,200 | 0.1 | 0.1 | 0.005 | 0.005 | 2,600 | 4m, M8/M12 plug | 0.51 | Ethernet |
|
|
FTE-AXIA80-Dual Si-75-4/Si-150-8 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-75-4 | Si-150-8 | 82 | 25.4 | aluminum | 64 | ± 75 | ± 235 | ± 4 | ± 4 | ± 2,350 | ± 7,500 | ± 40 | ± 40 | 1,500 | 0.04 | 0.04 | 0.002 | 0.002 | 1,500 | 4m, M8/M12 plug | 0.28 | EtherCat |
|
|
FTRS485-AXIA80-Dual Si-75-4/Si-150-8 |
Available upon quote | - | Si-75-4 | Si-150-8 | 82 | 25.4 | aluminum | 64 | ± 75 | ± 235 | ± 4 | ± 4 | ± 2,350 | ± 7,500 | ± 40 | ± 40 | 1,500 | 0.04 | 0.04 | 0.002 | 0.002 | 1,500 | - | 0.28 | Serial interface (RS-485) |
|
|
FTN-AXIA80-Dual Si-200-8/Si-500-20 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-200-8 | Si-500-20 | 82 | 25.4 | aluminum | 64 | ± 200 | ± 360 | ± 8 | ± 8 | ± 2,500 | ± 4,500 | ± 100 | ± 100 | 2,200 | 0.1 | 0.1 | 0.005 | 0.005 | 2,600 | 4m, M8/M12 plug | 0.3 | Ethernet |
|
|
FTE-AXIA80-Dual Si-200-8/Si-500-20 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-200-8 | Si-500-20 | 82 | 25.4 | aluminum | 64 | ± 200 | ± 360 | ± 8 | ± 8 | ± 2,500 | ± 4,500 | ± 100 | ± 100 | 2,200 | 0.1 | 0.1 | 0.005 | 0.005 | 2,600 | 4m, M8/M12 plug | 0.3 | EtherCat |
|
|
FTRS485-AXIA80-Dual Si-200-8/Si-500-20 |
Available upon quote | - | Si-200-8 | Si-500-20 | 82 | 25.4 | aluminum | 64 | ± 200 | ± 360 | ± 8 | ± 8 | ± 2,500 | ± 4,500 | ± 100 | ± 100 | 2,200 | 0.1 | 0.1 | 0.005 | 0.005 | 2,600 | - | 0.3 | Serial interface (RS-485) |
|
|
FTN-AXIA80-Dual Si-480-20/Si-1200-50 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-480-20 | Si-1200-50 | 82 | 25.4 | Stainless steel | 64 | ± 480 | ± 800 | ± 20 | ± 20 | ± 6,000 | ± 10,000 | ± 210 | ± 250 | 2,500 | 0.4 | 0.4 | 0.01 | 0.01 | 2,500 | 4m, M8/M12 plug | 0.68 | Ethernet |
|
|
FTE-AXIA80-Dual Si-480-20/Si-1200-50 |
Available upon quote | Y-shaped distributor 4m, M12/RJ-45 plug and 3-pole power supply (line from open) | Si-480-20 | Si-1200-50 | 82 | 25.4 | Stainless steel | 64 | ± 480 | ± 800 | ± 20 | ± 20 | ± 6,000 | ± 10,000 | ± 210 | ± 250 | 2,500 | 0.4 | 0.4 | 0.01 | 0.01 | 2,500 | 4m, M8/M12 plug | 0.68 | EtherCat |
|
|
FTRS485-AXIA80-Dual Si-480-20/Si-1200-50 |
Available upon quote | - | Si-480-20 | Si-1200-50 | 82 | 25.4 | Stainless steel | 64 | ± 480 | ± 800 | ± 20 | ± 20 | ± 6,000 | ± 10,000 | ± 210 | ± 250 | 2,500 | 0.4 | 0.4 | 0.01 | 0.01 | 2,500 | - | 0.68 | Serial interface (RS-485) |
Click on the part number for more information about each product
