Ultra -short pulse excitation laser ASCEND
Spectra-Physics
About This Product
The state -of -the -art ultra -short pulse oscillator and amplifier require a reliable high -performance pump laser.
Spectra-PHYSICS covers all basses with a wide range of excitation laser options, from joule-level pulse energy to the best CW green output.
ASCEND ™ Q Switch Green Laser is our main product of our ultra -short pulse and enhances the portfolio of the ultra -short pulse amplifier. The ASCEND series laser will evolve your research more. ASCEND is an industrial LD excitation solid Q -switch laser, and the output is 527 nm and 60 w or more.
Ideal for excitement of ultra -short pulse amplifier of SPITFIRE® ACE and Solstice Ace series. Provides the industry's most advanced output, energy, beam quality, and reliability, and provides the most efficient amplifier.
・ Ideal for excitation for ultra-short pulse amplifiers of Spectra-Physics
・ The best beam quality that realizes maximum efficiency
・ High reliability based on industrial platforms
■ Adopt super efficient cooling
ASCEND uses an ultra -efficient cooling system using its own technology to provide the highest stability and long -term reliability. By using SPECTRA-PHYSICS ultra-short pulse amplifier, it achieves low noise, high efficiency, and high reliability.
■ System configuration can be easily changed
ASCEND has a flexible design that can be variable in a repetition frequency in the range of 1 kHz to 10 kHz, so it can be selected from 60 W and 40 W as an output level that matches each ultra -short pulse amplifier system. 。
■ Providing reliability and cutting -edge performance that can withstand industrial applications
ASCEND has inherited the most high-performance, reliable LD excitation laser tradition, which has been committed to the industry for many years. In order to maximize the performance of SPECTRA-PHYSICS's ultra-short pulse amplifier system, it has a combination of state-of-the-art performance and industrial reliability and robustness.
-
Product
Ultra -short pulse excitation laser ASCEND
-
Handling Company
Spectra-Physics
2 Models of Ultra -short pulse excitation laser ASCEND
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Average power 10kHz | Average power 1kHz | Average power 5kHz | Beam -oriented stability | Beam diameter | Electrical requirements | Laser head dimensions | Laser head weight | Nominal repetition rate | Power cable length | Power stability (8 hours or more at a stable temperature) | Power supply dimensions | Power supply weight | Pulse energy 10kHz | Pulse energy 1kHz | Pulse energy 5kHz | Spatial mode | polarization | wavelength |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
ASCEND 60 |
Available upon quote | > 50 w | > 35 w | > 60 w | <10 µrad/℃ | 3mm (nominal) | AC110/230V, single phase, 60/50Hz, 2 × 15/10A | 50.8 × 25.4 × 17.9cm (20 × 10 × 7.1 inch) | 40 pounds (18kg) | 1 to 10kHz | Ambirical -2.95 m | <0.15%RMS | Rack mountable, 18 x 19 x 7 inches (45.47 x 48.26 x 17.53 cm) | 30 pounds (14kg) | > 5 MJ | > 35 MJ | > 12 MJ | Multi -mode | Linear, horizontal | 527nm |
|
|
ASCEND 40 |
Available upon quote | > 30W | > 25W | > 40W | <10 µrad/℃ | 3mm (nominal) | AC110/230V, single phase, 60/50Hz, 2 × 15/10A | 50.8 × 25.4 × 17.9cm (20 × 10 × 7.1 inch) | 40 pounds (18kg) | 1 to 10kHz | Ambirical -2.95 m | <0.15%RMS | Rack mountable, 18 x 19 x 7 inches (45.47 x 48.26 x 17.53 cm) | 30 pounds (14kg) | > 3MJ | > 25MJ | > 8MJ | Multi -mode | Linear, horizontal | 527nm |
Click on the part number for more information about each product
