IPC-3014-POE ++ | PoE -compatible media converter IPC series
Connection Technology Systems Co., Ltd.

Price (excluding tax)

Model Description

■ 2-port SFP / 1 port 30W RJ-45 /1 port 60W RJ-45 Industrial PoE ++ multifunctional media converter ・ PoE (60W) Power supply ・ 10/100/1000BASE-T⇔100/1000BASE-X ■ Characteristics ・ 100/1,000Mbps SFP dual rate x 2 ports ・ 10/100/1000BASE-T × 1 port (802.3AF/at compatible) ・ 10/100/1000BASE-T × 1 port (60W PoE ++ industrial multifunctional media converter) Transform into various optical fiber media, multi-mode, single mode, or two-way WDM with conventional twist pair RJ-45 cables, SC connectors.

Model Filter

You can search for other models from each index. The displayed value is the value of the currently selected part number.

External dimensions & weight

Hardware 1

Hardware 2

Interface

LED display

Operating environment

power supply

See all 2 models in list

Part Number
IPC-3014-POE ++

Product
PoE -compatible media converter IPC series

Handling Company
Connection Technology Systems Co., Ltd.

*Please note that we may not be able to accommodate sample requests.

PoE -compatible media converter IPC series IPC-3014-POE ++'s performance table

Items marked with have different values depending on the model number.

Product Image	Price (excluding tax)	External dimensions & weight	Hardware 1	Hardware 2	Interface	LED display	Operating environment	power supply
	Available upon quote	・ Body size: 36 x 110 x135mm (W x d x h) ・ Weight: 0.64kg ・ Housing: Aluminum, IP30	・ Store & forward ・ Auto negotiation (TP port) ・ MDI/MDIX Automatic identification (TP port) ・ Notification function (power disconnection, link break) ・ Auto & Force mode settings	・ Half/total double communication ・ MAC address table: 2K ・ Memory buffer: 128k bytes ・ Relay output ・ Surge protection: 6KV (K.21)	・ TP port: 2 x 10/100/1000BASE-T RJ-45 ・ F/O Port: 2 x 100/1000BASE-X SFP	・ P1, P2 ・ ALM, Mode ・ TP1, TP2 ・ PoE1, PoE2 ・ SFP1, SFP2	・ Operating temperature: -40 ° C ~ 75 ℃ ・ Storage time temperature: -40 ° C ~ 85 ℃ ・ Humidity: 5% to 90%, no condensation	・ DC power supply: - Terminal block X 1 (2 systems) --DC input power supply: 12 ~ 57VDC ・ Note: Use a power supply line with 14AWG or more ・ Power consumption: 96W (maximum)

There are 2 models for this product.
