About This Product
Achieves large capacity and high pressure injection with a solenoid driven pump.
■Large volume injection
There are 4 models available, ranging from 300 to 1,300mL/min.
■Suitable for high viscosity liquids
It can also be used to inject polymers (polymer flocculants).
*When transferring high viscosity liquids, the discharge rate may be lower than the specified maximum discharge rate depending on the liquid properties and conditions.
Direct input of injection volume, 3 patterns of injection volume settings available
■Setting by stroke speed
Setting range: 1 to 300 strokes/min (can be set in increments of 1 stroke/min)
■Setting by discharge amount
Setting range: 0.1~ (maximum discharge amount of selected model) mL/min (can be set in 0.1mL/min increments)
■Setting by percentage
Setting range: 1 to 100% (can be set in 1% increments, with maximum stroke number (300strokes/min) as 100%)
■Free power supply
With AC100 to 240V (±10%), there is no need to worry about the on-site supply voltage or voltage fluctuations. In addition, it can be used in a variety of sites and applications, so you can keep it in stock with confidence.
■Waterproof and dustproof specifications
IEC standard: IP65 equivalent
■One-shot calibration using actual discharge amount
Easy calibration function that automatically dispenses 300 strokes of chemical liquid. All you have to do is input the discharge amount into this machine, and you can easily perform accurate calibration using the actual flow rate.
■Analog input proportional control
Injection volume (stroke speed: 0 to 300 strokes/min) can be set according to external analog input signal (4 to 20 mA). It can be used for a wide range of purposes such as pH and residual chlorine control.
■Pulse input proportional control & external stop input control
In addition to ON/OFF control of the pump using external stop input, the injection volume (1/9,999 to 9,999 strokes/pulse) can also be set according to external pulse input signals. Various automatic controls can be easily performed by linking with pulse transmitting flowmeters and level meters.
■2-point level meter control
Controls alarm display/output, pump stop, etc. according to the amount of chemical solution remaining in the tank.
■Count operation (batch injection control) & interval operation (timer injection control)
・Count setting: 1 to 9,999strokes (×1,×10,×100,×1,000)
・Interval setting: ON time 1 to 9,999min, OFF time 1 to 9,999min
-
Product
Positive Displacement Pump Solenoid Driven Metering Pump Solenoid Driven Metering Pump PZiG
-
Handling Company
Takumina Co., Ltd.
-
Categories
5 Models of Positive Displacement Pump Solenoid Driven Metering Pump Solenoid Driven Metering Pump PZiG
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Maximum discharge pressure (MPa) | Maximum discharge volume (mL/min) |
|---|---|---|---|---|
|
|
PZiG-300 |
Available upon quote | 1 | 340 |
|
|
PZiG-500 |
Available upon quote | 0.7 | 530 |
|
|
PZiG-700 |
Available upon quote | 0.4 | 760 |
|
|
PZiG-1000 |
Available upon quote | 0.3 | 1,000 |
|
|
PZiG-1300 |
Available upon quote | 0.2 | 1,300 |
