Slurry pump SSH type
Maruhachi Pump Manufacturing Co., Ltd.
About This Product
We offer a variety of slurry pumps, including gland (W mechanism) pumps that do not require external water sealing and products that can easily transfer high concentration and high viscosity liquids. Excellent durability and wear resistance.
■Features
・Strong self-priming performance.
・Easy maintenance and high economic efficiency.
- Double mechanical seal that does not require external water sealing.
・Discharge head that can be freely selected by rotating speed.
■Applications
・Automotive, machinery industry ・Construction, quarrying, mining, civil engineering work ・Cement, concrete industry related
・Steel making, refining, ceramics, casting, electric power related
・Paper and pulp industry ・Water supply and sewage, garbage incinerators, community plants ・Petrochemical, chemical industry related
・Lumber, wood industry ・Ships, fisheries related
-
Product
Slurry pump SSH type
-
Handling Company
Maruhachi Pump Manufacturing Co., Ltd.
-
Categories
3 Models of Slurry pump SSH type
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Caliber | Discharge amount | Material Inner volute | Material back plate | Material casing | Material impeller | Material shaft | Number of motor poles | Shaft seal method | Total head |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
SSH-I for non-corrosive slurry |
Available upon quote | 40×32mm~100×80mm | 30L/min~1,000L/min (standard rotation speed) | FC200 | FC200 | FC200 | FC200 | SUS420J2 | 4P (1,450min^-1~2,900min^-1 50/60Hz) | Double mechanical seal method | 4.5m~41m |
|
|
SSH-Ⅲ for corrosive slurry |
Available upon quote | 40×32mm~100×80mm | 30L/min~1,000L/min (standard rotation speed) | SCS13 or 14 | SCS13 or 14 | SCS13 or 14 | SCS13 or 14 | SUS304 or 316 | 4P (1,450min^-1~2,900min^-1 50/60Hz) | Double mechanical seal method | 4.5m~41m |
|
|
SSH-Ⅳ for corrosive slurry |
Available upon quote | 40×32mm~100×80mm | 30L/min~1,000L/min (standard rotation speed) | Duplex stainless steel | Duplex stainless steel | SCS13 | Duplex stainless steel | SUS304 or 316 | 4P (1,450min^-1~2,900min^-1 50/60Hz) | Double mechanical seal method | 4.5m~41m |
Click on the part number for more information about each product
