Network equipment media converter DN100GE series
Daiden Co., Ltd.
About This Product
■Product features
・100Gbps high-speed optical transmission
・Remote monitoring function
・SNMP monitoring function
・Long distance transmission of over 100km is possible with built-in booster amplifier
・Multiplex transmission possible in combination with DWDM filter
Main features
■Optical transmission
Performs mutual conversion between 100GBASE-R4 signal and OTU4 signal. It has one QSFP28 and one CFP2-ACO interface.
■High-density mounting
Up to 4 units can be stored in a 1U size 19 inch rack.
■Remote monitoring function
When this product is connected as a counterpart, it is possible to check the operating status and power status of the remote side device using the LED.
■Remote monitoring
By installing it in the rack option "DNSHD8E-2P-MGT", you can monitor and control the link status and settings of this machine. It is also possible to read the status of the installed optical module.
■Long distance transmission using amplifier
By using a booster amplifier, the allowable loss can be improved by up to 20dB. The amplifier has a built-in MC, so it doesn't take up much space. You can choose with or without an amplifier depending on the model number.
■Multiple transmission of up to 8 lines
The CFP2-ACO's emission wavelength can be set to any wavelength from C13 to C61 from the management unit installed in DNSHD8E. By combining with MUX/DEMUX for DWDM (DNDWME series), multiplex transmission for up to 8 lines is possible.
■Link interlocking function
Although this product does not implement the LPT (Link Pass Through) function, the same effect can be obtained by using the LFS (Link Fault Signaling) function of the terminal device to which this product is connected.
-
Product
Network equipment media converter DN100GE series
-
Handling Company
Daiden Co., Ltd.
-
Categories
2 Models of Network equipment media converter DN100GE series
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Booster amplifier amplification wavelength range | Booster amplifier compatible optical fiber | Booster amplifier connector | Booster amplifier gain | Booster amplifier incidence range | Booster amplifier laser class | Booster amplifier noise figure | Booster amplifier output range | LED display (MODE1) | LED display (MODE1) OPT1 | LED display (MODE1) OPT2 | LED display (MODE1) PW | LED display (MODE1) R- | LED display (MODE1) R-OPT1 | LED display (MODE1) R-OPT2 | LED display (MODE1) R-PW | LED display (MODE2) | LED display (MODE2) OPT1 | LED display (MODE2) OPT2 | LED display (MODE2) PW | OPT1 port compatible interface | OPT1 port compliant standards | OPT1 port transmission code | OPT1 port transmission method | OPT1 port transmission speed | OPT2 port compatible interface | OPT2 port compliant standards | OPT2 port transmission code | OPT2 port transmission method | OPT2 port transmission speed |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
DN100GE |
$ 11,700.00〜 | - | - | - | - | - | - | - | - | Always off | When OPT1 port optical signal is received: Lights up (green) | When OPT2 port optical signal is received: Lights up (green) | When power is supplied: Lit (green) / When power is abnormal: Off / When MC is initialized: Flashing (green) | When remote status cannot be obtained: Flashing (green) |
Remote side OPT1 port display When receiving optical signal: Lit (green) / When remote status cannot be obtained: Blinking (green) |
Remote side OPT2 port display When receiving optical signal: Lit (green) / When remote status cannot be obtained: Blinking (green) |
Remote side power display When power is supplied: Lit (green) / When power is abnormal: Off / When MC is abnormal: Flashing (green) |
Always off |
OAM function display When OAM (remote monitoring) function is enabled: Lit (green) / When OAM (remote monitoring) function is disabled: Off |
OPT1 operation mode display When RS-FEC is enabled: Lit (green) /When RS-FEC is disabled: Off |
Always off | SFF-8665 | IEEE802.3ba/bm 100GBASE-R4 | 64B/66B code/64B/66B code+RS-FEC | Full duplex method | 103.125Gbps | OIF IA for CFP2-Analog Coherent Optics Module | ITU-T G.709 OTU4 | DP-QPSK | Full duplex method | 111.810Gbps |
|
|
DN100GE-B-AMP |
$ 15,925.00〜 | 1,527.99nm~1,568.36nm |
Silica-based single mode 1.31μm band zero dispersion optical fiber or 1.55 µm band zero dispersion optical (DSF) fiber |
LC (JIS C 5964-20, IEC61754-20) | Maximum 20dB | -5.0~+2.0dBm (VOA enabled) | Class 1M | 8.0dB or less | Always off | When OPT1 port optical signal is received: Lights up (green) | When OPT2 port optical signal is received: Lights up (green) | When power is supplied: Lit (green) / When power is abnormal: Off / When MC is initialized: Flashing (green) | When remote status cannot be obtained: Flashing (green) |
Remote side OPT1 port display When receiving optical signal: Lit (green) / When remote status cannot be obtained: Blinking (green) |
Remote side OPT2 port display When receiving optical signal: Lit (green) / When remote status cannot be obtained: Blinking (green) |
Remote side power display When power is supplied: Lit (green) / When power is abnormal: Off / When MC is abnormal: Flashing (green) |
Always off |
OAM function display When OAM (remote monitoring) function is enabled: Lit (green) / When OAM (remote monitoring) function is disabled: Off |
OPT1 operation mode display When RS-FEC is enabled: Lit (green) /When RS-FEC is disabled: Off |
Always off | SFF-8665 | IEEE802.3ba/bm 100GBASE-R4 | 64B/66B code/64B/66B code+RS-FEC | Full duplex method | 103.125Gbps | OIF IA for CFP2-Analog Coherent Optics Module | ITU-T G.709 OTU4 | DP-QPSK | Full duplex method | 111.810Gbps |
