Simple overhead wire carrier HANAKO A2 (Hanako A2)
Mori no Kikai Co., Ltd.
About This Product
■The brake mechanism reduces overhead line equipment and makes overhead line work safer.
・Ministry of Land, Infrastructure, Transport and Tourism's technical database (NETIS)
・Registration number: CB-220024-A
・Technical name: Catenary type carrier with brake
・Patented in Japan, America, Europe, and Asia
■For those in the landscaping industry, forest civil engineering industry, and special logging industry
・Removal of dangerous trees and wind-fallen trees
・Removal of discarded and thinned wood
・Sweet cleaning (removal of driftwood)
・For transporting materials
■For those in the forestry industry
・Transportation of mushroom logs
・Transportation of firewood, charcoal, and biomass
・For transporting forest products and fruits
■Features
・Equipped with a brake, which eliminates the limitations of a single power source (light overhead wire) and expands transportation conditions.
・One unit can handle all transportation conditions
■Suitable for both aerial transport and end-up and ground-pulling transport
If the ground clearance is increased, it can be transported in the air and then loaded onto a truck.
■ Dangerous unloading becomes safe
The lower part is safe because it automatically stops the load from falling.
■Suitable for lowering loads, lifting loads, and horizontal transportation
The movement route is the same regardless of the slope/the operating procedure is the same
■Empty carrier stopped
Stops at any position. No need to tie up when loading or unloading cargo
■Lightweight/no tools required
Made of duralumin, it is highly rigid yet lightweight at 8.5 kg.
■Standard support for 1 to 3 times power
Reduces shaking during aerial transportation by boosting power / Compatible with small power to human power
■Compatible with both fiber rope and wire rope
Compatible with any fixed rope by replacing the brake.
■Useful in places where heavy machinery cannot be used
・It is difficult to make a road. The road cannot be widened due to topographical and geological conditions.
・The approach is narrow and heavy machinery (cranes, construction machinery, forestry machinery) cannot approach.
・There are concerns that introducing large equipment will introduce new risks.
- There is a risk of coming into contact with artificial objects (buildings, etc.) or obstacles (existing trees, etc.)
It shows its power in situations such as.
■About this set
A combination that uses fiber rope as a fixed rope to reduce the burden of rope tensioning work. Suitable for transport up to 50m. This set comes with a fixed rope, making it safe for inexperienced users.
■What's included in this set
・Carrier body HANAKO A2x1 piece
・Brake x1 (for fiber rope/size 14)
・Exclusive clip x1
・Fixed fiber rope MainLine4814x1 (Φ14mmx59m)
The load that can be hung varies depending on the strength of the fixed rope. Main unit performance remains unchanged
-
Product
Simple overhead wire carrier HANAKO A2 (Hanako A2)
-
Handling Company
Mori no Kikai Co., Ltd.
-
Categories
1 Models of Simple overhead wire carrier HANAKO A2 (Hanako A2)
| Product Image | Part Number | Price (excluding tax) | Dedicated clip | Mass | Material | Size | Slope condition | Working load |
|---|---|---|---|---|---|---|---|---|
|
|
HNA2 |
Available upon quote |
Compatible with fiber ropes up to Φ10 mm and can be wrapped and fixed. Hand holes on both sides (for guidance when loading and unloading cargo) With magnetic catch (for joining to the main body when moving the empty carrier) |
Body: 8.5kg Total mass: 10.5kg Dedicated clip: 1.4kg *The weight of the main unit is the weight when carried, excluding the cover, brake, and special clip. The total mass is the mass excluding the special clip. |
Structure: Duralumin (aluminum alloy) Mechanism: stainless and carbon steel |
Body: 570mmx380mmx130mm Dedicated clip: 180mmx180mmx55mm |
-40 degrees (lowered load) ~+40 degrees (raised load) *This is the angle (elevation angle) of the fixed rope, not the angle of the ground. Also compatible with horizontal transport (0 angle) |
2,000N Maximum load capacity: 200kg for lifting and lifting / 100kg for aerial transport *The maximum load mass may change depending on the angle of inclination and the number of boosters, so please use this as a guide. |
