Chemical injection pump IDN series with analog intermittent operation control function
Cem Corporation Co., Ltd.
About This Product
Intermittent control operation of 15/30/60 seconds can be performed using analog control, and it can also be switched to continuous operation with a single touch.
■Features
- The diaphragm uses Teflon, which has excellent high pressure and chemical resistance. The balls are made of ceramic, etc. to achieve greater durability.
- Chemical resistance has also been improved by using a plastic molded product for the pump base.
- It is possible to memorize and save the operating status even during a power outage. In the case of water pump proportional injection, it is possible to inject water completely in proportion to the amount of pumped water without being affected by chattering etc.
・Flow rate adjustment is easy and easy to see. Air bleeding is also a one-touch operation, and chemical liquid can be easily sucked into the pump head during startup.
- Outdoor type and weekly timer equipped type are also available.
■Applications
- Injection of chlorine into drinking water.
- Injecting chlorine into pool and bath water.
-
Product
Chemical injection pump IDN series with analog intermittent operation control function
-
Handling Company
Cem Corporation Co., Ltd.
-
Categories
6 Models of Chemical injection pump IDN series with analog intermittent operation control function
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Continuous injection volume (ml/min) | Discharge pressure (Mpa) | Hose size | Intermittent operation minimum discharge amount (ml/min) | Intermittent operation setting time (sec) | Output (W) | Voltage (V) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
IDN03 |
Available upon quote | 22/26 | 0.35 | 5x9 | 0.8/1.0 | 15/30/60 | 3 | 100/1Φ200 | 3.6 |
|
|
IDN06 |
Available upon quote | 25/30 | 0.45 | 5x9 | 0.9/1.2 | 15/30/60 | 6 | 100/1Φ200 | 3.8 |
|
|
IDN30 |
Available upon quote | 30/36 | 1 | 5x9 | 1.2/1.4 | 15/30/60 | 15 | 100/1Φ200 | 5.2 |
|
|
IDN60 |
Available upon quote | 60/72 | 0.5 | 5x9 | 1.2/1.4 | 15/30/60 | 15 | 100/1Φ200 | 5.2 |
|
|
IDN150 |
Available upon quote | 150/180 | 1 | 6x11 | 5.0/6.0 | 15/30/60 | Twenty five | 100/1Φ200 | 5.7 |
|
|
IDN300 |
Available upon quote | 300/360 | 0.5 | 6x11 | 5.0/6.0 | 15/30/60 | Twenty five | 100/1Φ200 | 5.7 |
