General sensor Gyro sensor
Panasonic Industry Co., Ltd.

About This Product

■Product overview・Achieved a compact gyro sensor by using a MEMS tuning fork element and bare chip ASIC
・High reliability achieved by airtight SMD type package
・Built-in self-diagnosis function to adapt to system fail-safe

Principle of gyro sensor①
■What is angular velocity?Angular velocity = rotation speed (rotation angle per second)

■Gyro sensor output characteristics・Sensitivity: Output change amount for input angular velocity 1deg/sec (25mVdeg/s)
・0 point voltage: Output voltage at input angular velocity = 0 (at rest) (2.5V)

Principle of gyro sensor②
■ Coriolis forceThe "Coriolis force" is perpendicular to the direction of the pendulum's reciprocating motion and reaches its maximum at the maximum speed point.

■Operating principle (tuning fork type)If two orthogonal vibration modes can be electrically driven and detected independently, it becomes a gyro sensor → piezoelectric effect is used as the drive/detection method

How to use gyro sensor
■Skid prevention device (ESC)A system that uses a gyro sensor to detect the vehicle's turning speed and preventively prevents the vehicle from spinning (sideslip), dramatically increasing safety while driving.

■Rollover airbagA gyro sensor detects the vehicle's rollover speed, a computer determines the situation, and deploys curtain airbags.

Model
There is 1 model available for this product.

Product
General sensor Gyro sensor

Handling Company
Panasonic Industry Co., Ltd.

Categories

Sensors

Gyroscopic (Gyro) Sensors

Sensors

Seismic Sensor

Sensors

Angular Velocity Sensors

70+ people viewing

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

1 Models of General sensor Gyro sensor

Image	Part Number	Price (excluding tax)	Size (LxWxH) (mm)	Series/type	Type	Power supply voltage (DC) (V)
	EWTS64G	Available upon quote	10.0x9.7x4.9	MEMS gyro sensor for rollover detection	For rollover detection	5
