Centralized management of power consumption of offices and labs Watt-Monitor CCI-WM01H
Cybercraft Co., Ltd.
About This Product
■ Overview
・ Cybercraft's power consumption monitor “Watt-Monitor” will help you solve your concerns about power.
・ It is a device that intensively manages the power consumption of offices and labs.
・ It has a function to not only measure power consumption, but also accumulate, aggregate data, and observe long -term power consumption.
・ Despite compact, you can measure two power consumption at the same time.
・ It is the best tool for "visualization" of the appeal points of eco -friendly products.
■ Characteristics
・ AC100V (single -phase) 50/60Hz can be used
・ Rated current 3A
・ The measured power consumption is consolidated data on the computer by connecting Ethernet.
・ Comparison of power consumption of 2 products
・ Moving power consumption over a long period of time
・ Monitor a large number of power consumption by simultaneous use of multiple units
-
Product
Centralized management of power consumption of offices and labs Watt-Monitor CCI-WM01H
-
Handling Company
Cybercraft Co., Ltd.
-
Categories
1 Models of Centralized management of power consumption of offices and labs Watt-Monitor CCI-WM01H
| Product Image | Part Number | Price (excluding tax) | External I/F (LAN I/F) | External I/F (corresponding protocol) | Incidental power consumption | Maximum rated power | Measurement item | Measurement method | Measurement range (current) | Measurement range (frequency) | Measurement range (power rate) | Measurement range (power) | Measurement range (voltage) | Measuring line | Rated power supply voltage | size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
CCI-WM01H |
Available upon quote | IEEE802.3U (100BASE-TX) /Iee802.3 (10BASE-T) compliant | TCP/IP | 0.0 ~ about 10E+14wh | 300va | Voltage, current, effective power, power rate, frequency |
Voltage / current simultaneous digital sampling Sampling frequency: 25kHz Simultaneous measurement of 2 lines is possible |
0.00 ~ 3.00A (RMS) | 50.00 ~ 60.00Hz | 0.00 ~ 1.00 (no polarity display) | 0.00 ~ 300.0W | 90.0 ~ 115.0V (RMS) | Single -phase exchange | AC100V, 50/60Hz | 225W x 40H x 165D |
