High frequency guidance heating device handheld type TS series
S. workman-. Japan
About This Product
The TS series is a handheld type and is a very small model. The biggest feature is that the heated coil head can be moved freely, so you can aim at the heated object from various angles and change it freely.
Because the head is lightweight (1.5 kg), it can be installed on a robot, but it can also be used by workers. The installation location of the equipment is free, and the maintenance is easy.
■ Build automatic control such as low attachment (optional)
-The optional external controllers that are useful when using standalone can program pre -set automatic cycle control on the touch panel, and can easily build automatic control such as low attachment.
･ Heating output, timing, three steps, oxidation prevention gas, flux gas, cooling gas time, etc. can be set at the same time, and a total of 20 different cycle patterns can be set.
■ Effective for improvement
It is effective for heating composite metals, heating places (such as inside the refrigerator), and improving yields, which are difficult with gas rouge.
■ Easy operation
Because it is possible to hold it, anyone can use it for about 10 minutes training. Because the heating conditions are excellent, the productivity fluctuations due to the change of workers can be minimized.
■ Other features
･ 20 kinds of output and low gas control timing control can be preset. Automatically low heating can be achieved.
･ There is also a direct output type without a fever heated head. (Solded controller required)
■ Use
･ Air conditioner and refrigerator assembly line (robot) Row
･ Hot melt welded, hemming part adhesive hardening
･ Row of heat exchangeable parts
･ Burning swallow
･ Insert of plastic parts
･ Bearing, motor, etc., dried grilled swallow
･ Row of carbide tools
･ Burned and burned various tools, etc.
-
Product
High frequency guidance heating device handheld type TS series
-
Handling Company
S. workman-. Japan
1 Models of High frequency guidance heating device handheld type TS series
| Product Image | Part Number | Price (excluding tax) | Coil head size | Consistency | Cooling water | External signal | Input power supply | Output control | Output feeder cable | Protection circuit | Stability | body size | frequency | operation | option | output | weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
TS-100 / 12H |
Available upon quote | Φ53mm x 155 mml | Internal matching transformer | 0.3 ~ 0.4 mpa or 5 ~ 6 l / min. Necessary | Input signal: Heating start, interlock, alarm reset, external output control (4-20mA), control switching output signal: preparation, abnormality, driving, | AC 200V / 220V ± 10%, 3P, 50 / 60Hz, 12kva | PWFM phase control (5-100%) | 3m | Overcurrent (2 systems) protective circuits, cooling water pressure, water volume sensor, internal temperature sensor, input voltage monitoring sensor, matching defective detection sensor | Within 3% | W400 X H200 X D600 mm | 60kHz ~ 100 kHz | Output setting, alarm display | TS-CUT-1 external controller (sold separately) | 10 kw | About 50kg + 1.5kg (coil head) |
