Energy-saving and clean heating method that heats only the target metal High-frequency induction heating device
Toyo Electronics Industry Co., Ltd.
About This Product
Overview
■What is high frequency induction heating equipment?
High-frequency induction heating is a heating method that causes metal to self-heat without contact. IH cooking heaters used for cooking apply this principle. When a metal to be heated is placed inside a coil connected to an AC power source, a high-density eddy current is generated around the metal, generating heat, even though the coil and metal are separated. This process is called induction heating. High-frequency induction heating equipment consists of three elements: a high-frequency power supply, a matching section, and a heating coil.
■High frequency power supply
This is a device for outputting high frequency power. Specifically, it is a device that generates a ~50kHz square wave AC voltage according to the resonance state of the load.
■Consolidation section
It consists of a resonant capacitor and a matching transformer. The resonant frequency is determined by the combination of the resonant capacitor, matching transformer, and heating coil.
■Heating coil
The metal to be heated is placed inside this coil. The magnetic flux generated by the coil is passed through the metal, creating an eddy current (induced current). This allows the metal to be heated.
Product features
■Space saving
This is a compact high-frequency oscillator with an optimized equipment layout, including small IGBTs and laminated copper bars. Contributes to space saving of the entire equipment.
■Low price
In-house design and in-house production greatly reduces manufacturing costs.
■Energy saving
Our unique resonance control automatically corrects the frequency according to load fluctuations. Highly efficient power transmission reduces power consumption.
■High versatility
It has a built-in PLC function, and various parameters can be easily changed by simply connecting it to a computer.
■Equipped with data logging function
For traceability, various data can be logged and output to the touch panel. By building a system, we will realize IoT in factories and equipment.
■System integration
By combining this with YUTAKA's proud robot integration technology, it is possible to propose an optimal system that includes pre- and post-processing and transportation.
■Main implementation results
・Induction hardening/tempering robot system
・Shrink fitting system
・Electric heating system
・Pre-casting heating robot system
・Annealing system
-
Product
Energy-saving and clean heating method that heats only the target metal High-frequency induction heating device
-
Handling Company
Toyo Electronics Industry Co., Ltd.
-
Categories
1 Models of Energy-saving and clean heating method that heats only the target metal High-frequency induction heating device
| Product Image | Part Number | Price (excluding tax) | Control method | Cooling method | External dimensions (W×H×D) (mm) | Input specifications | Inverter | Output specifications Frequency (kHz) | Output specifications Power (kW) | Standard external interface |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
YPC-03075 |
Available upon quote | Pulse width control (PWM) | Water cooled | 600×1,010×450 | 3φ3W 400/420V±10% 50/60Hz | IGBT | 0.05~3 | 75 | FL-net, CAN, computer link |
