Dino-Lite Premier E 500X
Thanko
About This Product
Main functions of Dino-Lite Premier E500X
■ Realization of ultra -high magnification 500 times
Achieve 500 times ultra -high magnification. It is powerful when a large enlargement rate is required, such as industrial, research, and science.
■ Equipped with a one -touch shooting button
The touch switch on the body allows you to record images without touching your computer. You can shoot as it is with the body on hand, so you will not miss a chance.
■ High -performance DINOCAPTURE2.0 software with new features is included
You can observe it on the monitor or save it as a video or still image. It has advanced functions, such as various tools that measure the size and angle of the object, as well as automatic distance measurement, automatic discrimination, IP camera, and barcode reading. You can also increase the measurement accuracy by calibration (comparative).
■ A new body and performance up
1. Connection design to prevent cable disconnection
2. Reduce the use of adhesives as much as possible and increase body rigidity
3. Improved the movement of the image while adjusting the focus. Easy to adjust precise adjustment even at high magnification.
4. Improved magnification dial movement. Move to each magnification smoothly.
5. Prevention of static electricity.
-
Product
Dino-Lite Premier E 500X
-
Handling Company
Thanko
1 Models of Dino-Lite Premier E 500X
| Product Image | Part Number | Price (excluding tax) | Adjust confirmation rule | Exposure / correction | Jan | Magnification / Others | Package size | Supported OS | Warranty period | Weight (including package) | accessories | frame rate | interface | others | power supply | resolution | sensor | size | weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
Dinoam3113T5 |
$ 202.80〜 | CE, FCC, Rohs | Automatic exposure / automatic correction / automatic color balance / saturation / contrast correction | 456233176339 | About 500 times (single focus) ** This product is a high -magnification model, so it may be difficult to adjust the focus by hand depending on the application. In that case, we recommend using a dedicated stand (sold separately). Click here for the magnification | Width 163 x depth 163 x height 60 (mm) | Windows Vista / 7/8/10, Mac OSX 10.5 or later (only Intelmac is compatible, microclock is not available) | 1 year | 301g | Body, software CD-ROM, calibration sheet, warranty, storage bag, cable band | 30fps | USB2.0 | Eight white LED lights, measuring functions ( *), calibration functions * The magnification of the main unit is a standard. You can measure accurate values with dedicated software. | USB bus power | VGA (640 x 480), about 300,000 pixels | 0.3MPixels, 1 /4 inch CMOS | Width 32 x depth 93 x height 32 (mm) | 92g |
