XYθ-axis stage [3-axis stage: φ40mm/φ60mm] For positioning on a flat surface!-TSC3-40

XYθ-axis stage [3-axis stage: φ40mm/φ60mm] For positioning on a flat surface!-TSC3-60

XYθ-axis stage [3-axis stage: φ40mm/φ60mm] For positioning on a flat surface!
Tsukumo Engineering Co., Ltd.

Tsukumo Engineering Co., Ltd.'s Response Status

Response Rate

100.0%

Response Time

0.6hours

Very Fast Response

About This Product

■Summary・The XYθ-axis stage is a stage that allows fine adjustment in 3-axis directions.
・Since the fixed sample can be positioned with high precision, it is also useful for non-optical applications (such as jigs for measurement and analysis).
- Positioning on the XY axes and fine adjustment in 360° directions by rotating the θ axis are possible.
- In the photo, the adjustment functions are configured in the order of X-axis, Y-axis, and θ-axis from the bottom.
・Travel amount TSC3-40: X, Y ±6.5mm, θ coarse movement 360° & fine movement ±5°
・Travel amount TSC3-60: X, Y ±6.5mm, θ coarse movement 360° & fine movement ±5°

【supplement】
The method for determining each axis of our products is as follows (directions are explained in the photo).
・Z-axis direction: from bottom to top
・X-axis direction: From the front right to the back left (parallel to the optical axis)
・Y-axis direction: Direction from front left to back right (direction perpendicular to Z-axis and X-axis)
・α-axis: Expresses the rotational degree of freedom around the X-axis (rolling)
・β-axis: Expresses the rotational degree of freedom around the Y-axis (pitching)
・θ-axis: Expresses the rotational degree of freedom around the Z-axis (yawing)

Model
There are 2 models available for this product.

Product
XYθ-axis stage [3-axis stage: φ40mm/φ60mm] For positioning on a flat surface!

Handling Company
Tsukumo Engineering Co., Ltd.

Categories

Stages

Precision Stages

Stages

Positioning Stages

150+ people viewing

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

2 Models of XYθ-axis stage [3-axis stage: φ40mm/φ60mm] For positioning on a flat surface!

Click on the part number for more information about each product

Image	Part Number	Price (excluding tax)	Mass	Load capacity	Operation direction	Table size
	TSC3-40	$ 507.00〜	0.33 kg	2kgf (19.6N)	XYθ axis (3 axes)	Φ40 mm
	TSC3-60	$ 598.00〜	0.73kg	5kgf (49N)	XYθ axis (3 axes)	Φ60mm

Click on the part number for more information about each product
