Deburring machine/buffing machine ideal for precision finishing and sheet metal work BURRY TACK Ⅱ-CT type (dry type) /-CT-W type (wet type)-BURRY TACK Ⅱ-CT type

-CT-W type (wet type)
Toban Industries Co., Ltd.

Toban Industries Co., Ltd.'s Response Status

Response Rate

100.0%

Response Time

68.2hours

About This Product

This is a model that mainly targets burrs that occur during the sheet metal processing process. We automatically process burrs generated by turret punch presses, laser processing, press punching, shearing, etc. The target workpiece is firmly gripped by the feed rolls installed above and below, and is transported reliably to prevent it from shifting or flying off. Therefore, for large workpieces, it is possible to polish and polish a clean, even burr finish.

Similar to Type III, we have two models: a "dry type" that performs dry machining, and a "wet type" that applies water-soluble grinding fluid.

■Transportation departmentThe transport section uses a roll transport type. Products are sandwiched between rolls and sent. Two polishing wheels are installed for deburring one side of the workpiece, so even high burrs can be stably deburred without the workpiece shifting or flying off due to the strong pressure of the polishing wheels. . The feed roll uses a rubber roll to avoid scratching the product.

■OptionsDry types usually come with an optional dust collector. On the other hand, the wet type requires filtering of the grinding fluid, so it is equipped with a filtration device.

*In addition to products, we also develop tools such as brushes in-house.

Model
There are 2 models for this product.

Product
Deburring machine/buffing machine ideal for precision finishing and sheet metal work BURRY TACK Ⅱ-CT type (dry type) /-CT-W type (wet type)

Handling Company
Toban Industries Co., Ltd.

Categories

Machining / Machine Tools

Deburring Machinery

Machining / Machine Tools

Buffing Machinery

120+ people viewing

Last viewed: 21 hours ago

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

2 Models of Deburring machine/buffing machine ideal for precision finishing and sheet metal work BURRY TACK Ⅱ-CT type (dry type) /-CT-W type (wet type)

Click on the part number for more information about each product

Image	Part Number	Price (excluding tax)	Feed speed	Wet type specification	Machine dimensions	Plate length (min. to max.)	Plate thickness	Maximum board width	Dry type specification
	BURRY TACK Ⅱ-CT type	Available upon quote	0 ~ 8 (m/min)	-	W1485 x L1070 x H1060 (mm), 1000 (kg) *Dimensions for width 300mm specification	150 mm or more ~ unlimited	0.5t ~ 5.0t	300, 600, 900 (mm)	Dust collector 0.75kW ~
	BURRY TACK Ⅱ-CT-W type	Available upon quote	0 ~ 8 (m/min)	Filtration device 1.0kW ~	W1485 x L1070 x H1060 (mm), 1000 (kg) *Dimensions for width 300mm specification	150 mm or more ~ unlimited	0.5t ~ 5.0t	300, 600, 900 (mm)	-

Click on the part number for more information about each product
