Ultrasonic homogenizer UX-050
Mitsui Electric Seiki Co., Ltd.
About This Product
■Ultrasonic homogenizer
The ultrasonic homogenizer is a product that Mitsui Electric Seiki has been manufacturing and selling as a purely domestic manufacturer for over 30 years, and has sold about 150 units a year.
Ultrasonic homogenizers are widely used in the field of biochemistry, including crushing bacterial cells, dispersing minerals, and promoting reactions. Carbon nanotube dispersion, which has been attracting attention in recent years, is said to be most suitable for processing with an ultrasonic homogenizer, which can also disperse very hard samples such as ceramics and pigments, and can also disperse nanocarbons and diamonds. We have a proven track record.
■Principle of ultrasonic homogenizer
The ultrasonic homogenizer consists of an oscillator and a vibrator. The principle of ultrasonic dispersion is that the output sent from an oscillator is converted into vibration by a vibrating element inside the vibrator, and the tip at the tip of the vibrator generates longitudinal vibrations approximately 20,000 times per second. When this vibration is performed in a liquid, pressure is repeatedly applied and depressurized in the liquid, and vacuum bubbles are repeatedly generated and burst in the liquid.
The moment a vacuum bubble bursts or collapses in the liquid, a large shock wave occurs, creating large turbulence in the liquid, and the particles in the liquid are torn off or collided with each other, making them atomized. This principle is used as the dispersion mechanism of an ultrasonic homogenizer.
The main feature of the ultrasonic homogenizer is that it does not apply physical impact force, but rather just collides particles, etc., so the final particle size is relatively spherical, so it can be used in the final process of dispersion, or in particle size distribution systems. It is often used for pretreatment.
■Ultrasonic homogenizer UX-050
The UX-050 ultrasonic homogenizer (ultrasonic dispersion machine) is a simple ultrasonic homogenizer (ultrasonic dispersion machine) that is handy and can be oscillated by pressing a switch on the hand. The main purpose varies depending on the field.
■Chemical field
It is used for emulsifying and dispersing small quantities, and is used for dispersing rare materials and dispersing small quantities.
■Bio field
It is used to crush and cut bacterial cells, and is also used to crush DNA, crush hyphae, and prepare liposomes.
It has many uses and is a device that can be used in a variety of situations.
-
Product
Ultrasonic homogenizer UX-050
-
Handling Company
Mitsui Electric Seiki Co., Ltd.
-
Categories
1 Models of Ultrasonic homogenizer UX-050
| Product Image | Part Number | Price (excluding tax) | Chip | Driving mode | Frequency | Maximum output | Optional chip UMS-2 | Optional chip UMS-3 | Optional chip UMS-6 | Oscillator dimensions | Oscillator weight | Timer | Transducer dimensions | Tuning | Utility |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
UX-050 |
Available upon quote |
UMS-3 (Microchip step type φ3) *Standard accessory |
Timer operation/interval operation | 20kHz±1kHz | MAX-50W |
UMS-2 (Microchip step type φ2) Estimated processing amount: 0.1ml~10ml |
UMS-3 (Microchip step type φ3) *Standard accessory Estimated processing amount: 0.25ml~25ml |
UMS-6 (Microchip step type φ6) Estimated processing amount: 2ml~50ml |
H286×W156×D308 (mm) | Approximately 5.6kg | 1sec~120min | Φ40×226L | Auto tuning | AC100V 1A |
