USB color camera module MD-5014
Weld Vision LLC
About This Product
Compact USB camera module with ultra-full high-definition image quality
■Product features
・φ14mm small 5 megapixel CMOS USB color camera module
・High image quality (maximum 2,592 x 1,944 pixels, 1/4” QSXGA CMOS sensor adopted)
・3 types: 2 types of manual focus (dedicated lens type, type that can use commercially available M12 lenses), auto focus (60mm to ∞)
・①Manual focus lens (dedicated): f3.0mm/F2 (angle of view 74°),②Manual focus lens (M12 lens),③Autofocus lens: f3.87mm/F2.8 (angle of view 60°)
・General USB capture software can be used with USB2.0 output. (driver free)
・Resolution, brightness, contrast, and other camera settings can be configured via USB.
■Number of effective pixels
2,592×1,944 pixels/10fps, 2,048×1,536 pixels/20fps, 1,920×1,080 pixels/30fps, 1,2 80×720 pixels/30fps, 1,024×768 pixels/30fps, 640×480 pixels/30fps, 320×240 pixels/30fps
■Lens (diagonal angle of view) *Manual focus
・74° when resolution is 2,592×1,944, 1,280×720, 1,024×768, 640×480, 320×240
・62° when resolution is 2,048×1,536
・54° when resolution is 1,920×1,080
■Lens (diagonal angle of view) *Auto focus
・60° when resolution is 2,592×1,944, 1,280×720, 1,024×768, 640×480, 320×240
・49° when resolution is 2,048×1,536
・43° when resolution is 1,920×1,080
-
Product
USB color camera module MD-5014
-
Handling Company
Weld Vision LLC
-
Categories
3 Models of USB color camera module MD-5014
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Current consumption | Dynamic range | Effective size | Focal position | Image sensor | Interface | LED lighting | Operating temperature range | Output connector | Pixel size | Power supply | Shutter method | Specification | Storage temperature range |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
MD-5014B-MF |
Available upon quote | 170mA | 63dB | 3,651 um×2 744 um | 5mm~∞ | 1/4" QSXGA CMOS | USB2.0 | Option | -10 to 45℃ | MicroUSB (board body) *The attached cable is TypeA (microUSB and TypeC are also available) | 1.4um×1.4um | DC 5V | Rolling shutter | Manual focus 5M pixels | -30 to 60℃ |
|
|
MD-5014-MF-S |
Available upon quote | 170mA | 63dB | 3,651 um×2 744 um | 5mm~∞ | 1/4" QSXGA CMOS | USB2.0 | Option | -10 to 45℃ | MicroUSB (board body) *The attached cable is TypeA (microUSB and TypeC are also available) | 1.4um×1.4um | DC 5V | Rolling shutter | Compatible with M12 lens, no lens, 5M pixels | -30 to 60℃ |
|
|
MD-5014B-AF |
Available upon quote | 170mA | 63dB | 3,651 um×2 744 um | 60mm~∞ | 1/4" QSXGA CMOS | USB2.0 | Option | -10 to 45℃ | MicroUSB (board body) *The attached cable is TypeA (microUSB and TypeC are also available) | 1.4um×1.4um | DC 5V | Rolling shutter | Autofocus 5M pixels | -30 to 60℃ |
