Laser drone Terra Lidar X TLX20 series equipped with RIEGL mini VUX series
Terra Drone Co., Ltd.
About This Product
■TLX20 series
The IMU specs are higher than the TLX15 series, allowing highly accurate measurements even when flying at higher altitudes. A standard high-spec model.
■Recommended for the following people
・Those who are considering purchasing a new laser drone
・Those who are interested in high-precision laser drones
・Those who want to use laser drones for as-built construction and construction surveying
■What is Terra Lidar X?
High-precision laser with map accuracy within 5cm.
*Select from 6 models to suit your needs.
*It is assumed that measurements will be made under appropriate conditions for each individual site.
■High-precision, high-quality irradiation system equipped with a high-end model scanner
Utilizing our experience in developing proprietary technology since the spread of UAV-mounted laser systems, we have developed RIEGL's high-end scanners, which are globally trusted for their high-quality laser performance, and the Geospatial Information Authority of Japan's Work Regulations Using UAVs. Equipped with a high-performance IMU that meets various standards listed in the ``Rules'', we have achieved a highly accurate and high-quality irradiation system.
■Achieving low prices through our in-house developed domestic UAV LiDAR system and cloud analysis
By combining a domestically produced LiDAR system with overwhelmingly low operating costs and fast cloud analysis, we have achieved high accuracy at a low price.
■A complete customer support system where the entire team handles the installation, ordering, and operation processes.
We provide all-in-one support not only from installation to operation, but also support for ordering so that our customers can utilize our services over the long term. In addition, thanks to our ``Customer Support Team,'' a specialized team that supports customers' utilization, 90% of users are using it at two or more sites within four months of its introduction.
■Introduction support
We support customers' smooth implementation with a 3-step training course. We provide various manuals to support the use of drones, from how to operate them to filing flight applications with the government.
■Video course
Through the videos, you can acquire the knowledge necessary for introduction.
■WEB interview
Questions and answers for video training, advance preparation for on-site training, and consultation regarding future use will be resolved through a web interview.
■On-site training
Staff will accompany you to the actual site and provide support at the flight site. You will fly the drone while receiving explanations of what to do and what to watch out for depending on the situation.
・Basic knowledge of UAV drones
・Precautions when measuring
・Actual operation method, etc.
-
Product
Laser drone Terra Lidar X TLX20 series equipped with RIEGL mini VUX series
-
Handling Company
Terra Drone Co., Ltd.
-
Categories
2 Models of Laser drone Terra Lidar X TLX20 series equipped with RIEGL mini VUX series
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Deliverable accuracy | IMU | Irradiation angle | Map accuracy | Measurement efficiency (1 flight) | Mountable UAV | Number of echoes | Number of irradiation points | On-board scanner | Recommended altitude | Scanner accuracy |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
TLX1-20 |
Available upon quote | Within 5cm |
Applanix APX-15UAV *IMU: A sensor that detects how much the aircraft shakes. It detects tilting and shaking and uses it for correction during later analysis. |
360° |
5cm *Assumes measurement under appropriate conditions for each site. |
100 points/m2 17Ha 400 points/m2 5Ha *Measurement efficiency: A theoretical value calculated from the average area of one flight assuming that multiple flights will be flown at the same location if point density interpolation is required. |
Matrice 350 RTK (DJI) / Build Flyer (Ishikawa Energy Research) | Max 5 | 100,000 points/second | RIEGL mini VUX series | 70-100m | 1.5cm |
|
|
TLX3-20 |
Available upon quote | Within 5cm |
Applanix APX-15UAV *IMU: A sensor that detects how much the aircraft shakes. It detects tilting and shaking and uses it for correction during later analysis. |
120° (180° 200,000 points/second, 360° 100,000 points/second) *Can be changed with custom settings |
5cm *Assumes measurement under appropriate conditions for each site. |
100 points/m2 51Ha 400 points/m2 15Ha *Measurement efficiency: A theoretical value calculated from the average area of one flight assuming that multiple flights will be flown at the same location if point density interpolation is required. |
Matrice 350 RTK (DJI) / Build Flyer (Ishikawa Energy Research) | Max 5 | 300,000 points/second | RIEGL mini VUX series | 70-100m | 1.5cm |
