High-performance fanless panel PC equipped with Intel 7th generation Core-i5 CPU
Wincomm Japan Co., Ltd.
About This Product
■Main features
・Completely fanless despite being equipped with a high-performance CPU (thermal solution with fanless design)
・Highly reliable design with consideration for industrial embedded systems
・Intel 7th generation Core-i5-7200U-2.5GHz (Dual Core) standard installed
・Full flat front bezel compliant with IP66 dustproof and waterproof rating
・LED backlight is used for the liquid crystal panel
・Equipped with shock absorption HDD mechanism as standard
・DP (Display Port) x 2 included as standard (can output to two independent monitors)
・1 Gbps compatible RJ-45 connector x 2 slots included as standard
・Portrait mode support allows you to switch between portrait and landscape display
・VCCI/FCC/CE Class B certification for "interference electromagnetic wave regulation" that can be used in general homes and office environments
・Watch Dog function enables automatic recovery even when the OS hangs
- PXE LAN function allows for easy module updates from the server.
・ATX power supply (automatically turns on when AC/DC adapter is installed or DC input)
・Mini PCIe x 2 slots (Wireless LAN card and other devices can be used at the same time) "Wireless LAN" and "Wireless LAN + Bluetooth (BT)" modules can be added as options
-
Product
High-performance fanless panel PC equipped with Intel 7th generation Core-i5 CPU
-
Handling Company
Wincomm Japan Co., Ltd.
-
Categories
5 Models of High-performance fanless panel PC equipped with Intel 7th generation Core-i5 CPU
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | AC power supply | Audio | Audio jack | CPU | Chip set | Dc power supply | Disk interface | Expansion slot | External dimensions (panel mount) | External video output connector | LAN connector | LAN controller | LCD display section | LED indicator | Main memory | Operating humidity | Operating temperature | Power button | Power consumption | Serial connector | Storage | Support OS | Touch panel | USB connector | VGA | Watchdog Timer |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
WLP-7F20-15 |
Available upon quote | 100V~240V (standard AC adapter included) / 47~63Hz |
・Realtek Audio Codec ・2+2 W power up |
Audio Line-Out and Microphone In | Intel 7th Generation Core-i5-7200U-2.5GHz [Built-in Intel HD Graphics 620] | SoC | DC power supply: +12V ~ 28V universal (DC cable optional) | SATA 3 controller | Mini PCIe socket x 2 (internal slot: wireless LAN card and other devices can be used at the same time) |
・Approx. 398mm x 330mm x 86mm (approx. 6kg: excluding AC adapter) ・With VESA standard 75 x 75 mm pit mounting holes (on the back of the main unit) |
DP (Display Port) x 2 ports (can output to two independent monitors) | RJ-45 connector (IEEE 10/100/1000 Base-Tx Fast Ehernet) x 2 slots | 2x Intel Gigabit Ethernet | 15” TFT color (XGA resolution: 1,024 x 768) with LED backlight | When power is on: lights up in green, when HDD is accessed: flashes in orange | DDR4 SODIMM socket x 2 slots: Standard 4GB (expandable up to 32GB) [High brightness/wide range operation optional version: DDR3 WT RAM: 4GB (maximum 16GB)] | 10%~90% (no condensation) |
・0℃~40℃ (natural convection) ・0℃~50℃ (Forced convection of 1.0m/s according to IEC60068-2-56 standard at DC12V input) |
Non-locking push button, for power ON/OFF (when the power is turned on, pressing the button once will issue a shutdown command and turn the power off) | Approx. 45 W (maximum, excluding AC/DC adapter) | D-Sub 9-pin connector x 3 ports (1 port can be switched to RS-232/422/485 in BIOS) | Equipped with 1 x 2.5" Serial ATA HDD: 500GB standard (Flash memory can be changed to SSD as an option) [High brightness/wide range operation optional version: SSD MLC WT version: 128GB] |
・Windows 10 IoT Enterprise 2019/2021 LTSC 64bit ・Linux can be installed (However, the customer will need to provide their own support.) |
・Uses a highly durable resistive film type (5-wire type: key press life approximately 36 million times) touch panel ・Option: Equipped with projected capacitive touch panel (4 points/multi) [7H surface hardness, 100 million keystroke life] |
4 USB 3.0 ports | Intel Integrated HD Graphic 620 | Set from 1 to 255 minutes |
|
|
WLP-7F20-16 |
Available upon quote | 100V~240V (standard AC adapter included) / 47~63Hz |
・Realtek Audio Codec ・2+2 W power up |
Audio Line-Out and Microphone In | Intel 7th Generation Core-i5-7200U-2.5GHz [Built-in Intel HD Graphics 620] | SoC | DC power supply: +12V ~ 28V universal (DC cable optional) | SATA 3 controller | Mini PCIe socket x 2 (internal slot: wireless LAN card and other devices can be used at the same time) |
・Approx. 452mm x 330mm x 86mm (approx. 8kg: excluding AC adapter) ・With VESA standard 75 x 75 mm pit mounting holes (on the back of the main unit) |
DP (Display Port) x 2 ports (can output to two independent monitors) | RJ-45 connector (IEEE 10/100/1000 Base-Tx Fast Ehernet) x 2 slots | 2x Intel Gigabit Ethernet | 16-inch wide LCD TFT color (WXGA resolution: 1,366 x 768) with LED backlight | When power is on: lights up in green, when HDD is accessed: flashes in orange | DDR4 SODIMM socket x 2 slots: Standard 4GB (expandable up to 32GB) | 10%~90% (no condensation) |
・0℃~40℃ (natural convection) ・0℃~50℃ (Forced convection of 1.0m/s according to IEC60068-2-56 standard at DC12V input) |
Non-locking push button, for power ON/OFF (when the power is turned on, pressing the button once will issue a shutdown command and turn the power off) | Approx. 58 W (maximum, excluding AC/DC adapter) | D-Sub 9-pin connector x 3 ports (1 port can be switched to RS-232/422/485 in BIOS) | Equipped with 1 x 2.5" Serial ATA HDD: 500GB standard (can be changed to flash memory SSD as an option) |
・Windows 10 IoT Enterprise 2019/2021 LTSC 64bit ・Linux can be installed (However, the customer will need to provide their own support.) |
・Uses a highly durable resistive film type (5-wire type: key press life approximately 36 million times) touch panel ・Option: Equipped with projected capacitive touch panel (4 points/multi) [7H surface hardness, 100 million keystroke life] |
4 USB 3.0 ports | Intel Integrated HD Graphic 620 | Set from 1 to 255 minutes |
|
|
WLP-7F20-17 |
Available upon quote | 100V~240V (standard AC adapter included) / 47~63Hz |
・Realtek Audio Codec ・2+2 W power up |
Audio Line-Out and Microphone In | Intel 7th Generation Core-i5-7200U-2.5GHz [Built-in Intel HD Graphics 620] | SoC | DC power supply: +12V ~ 28V universal (DC cable optional) | SATA 3 controller | Mini PCIe socket x 2 (internal slot: wireless LAN card and other devices can be used at the same time) |
・Approx. 426.2mm x 358.6mm x 90mm (approx. 8.5kg: excluding AC adapter) ・With VESA standard 75 x 75 mm pit mounting holes (on the back of the main unit) |
DP (Display Port) x 2 ports (can output to two independent monitors) | RJ-45 connector (IEEE 10/100/1000 Base-Tx Fast Ehernet) x 2 slots | 2x Intel Gigabit Ethernet | 17” TFT color (SXGA resolution: 1,280 x 1,024) with LED backlight | When power is on: lights up in green, when HDD is accessed: flashes in orange | DDR4 SODIMM socket x 2 slots: Standard 4GB (expandable up to 32GB) | 10%~90% (no condensation) |
・0℃~40℃ (natural convection) ・0℃~50℃ (Forced convection of 1.0m/s according to IEC60068-2-56 standard at DC12V input) |
Non-locking push button, for power ON/OFF (when the power is turned on, pressing the button once will issue a shutdown command and turn the power off) | Approx. 62 W (maximum, excluding AC/DC adapter) | D-Sub 9-pin connector x 3 ports (1 port can be switched to RS-232/422/485 in BIOS) | Equipped with 1 x 2.5" Serial ATA HDD: 500GB standard (can be changed to flash memory SSD as an option) |
・Windows 10 IoT Enterprise 2019/2021 LTSC 64bit ・Linux can be installed (However, the customer will need to provide their own support.) |
・Uses a highly durable resistive film type (5-wire type: key press life approximately 36 million times) touch panel ・Option: Equipped with projected capacitive touch panel (4 points/multi) [7H surface hardness, 100 million keystroke life] |
4 USB 3.0 ports | Intel Integrated HD Graphic 620 | Set from 1 to 255 minutes |
|
|
WLP-7F20-19 |
Available upon quote | 100V~240V (standard AC adapter included) / 47~63Hz |
・Realtek Audio Codec ・2+2 W power up |
Audio Line-Out and Microphone In | Intel 7th Generation Core-i5-7200U-2.5GHz [Built-in Intel HD Graphics 620] | SoC | DC power supply: +12V ~ 28V universal (DC cable optional) | SATA 3 controller | Mini PCIe socket x 2 (internal slot: wireless LAN card and other devices can be used at the same time) |
・Approx. 495.5mm x 384.mm x 91.5mm (approx. 9.2kg: excluding AC adapter) ・With VESA standard 75 x 75 mm pit mounting holes (on the back of the main unit) |
DP (Display Port) x 2 ports (can output to two independent monitors) | RJ-45 connector (IEEE 10/100/1000 Base-Tx Fast Ehernet) x 2 slots | 2x Intel Gigabit Ethernet | 19” TFT color (SXGA resolution: 1,280 x 1,024) with LED backlight | When power is on: lights up in green, when HDD is accessed: flashes in orange | DDR4 SODIMM socket x 2 slots: Standard 4GB (expandable up to 32GB) [High brightness/wide range operation optional version: DDR3 WT RAM: 4GB (maximum 16GB)] | 10%~90% (no condensation) |
・0℃~40℃ (natural convection) ・0℃~50℃ (Forced convection of 1.0m/s according to IEC60068-2-56 standard at DC12V input) |
Non-locking push button, for power ON/OFF (when the power is turned on, pressing the button once will issue a shutdown command and turn the power off) | Approx. 65 W (maximum, excluding AC/DC adapter) | D-Sub 9-pin connector x 3 ports (1 port can be switched to RS-232/422/485 in BIOS) | Equipped with 1 x 2.5" Serial ATA HDD: 500GB standard (Flash memory can be changed to SSD as an option) [High brightness/wide range operation optional version: SSD MLC WT version: 128GB] |
・Windows 10 IoT Enterprise 2019/2021 LTSC 64bit ・Linux can be installed (However, the customer will need to provide their own support.) |
・Uses a highly durable resistive film type (5-wire type: key press life approximately 36 million times) touch panel ・Option: Equipped with projected capacitive touch panel (4 points/multi) [7H surface hardness, 100 million keystroke life] |
4 USB 3.0 ports | Intel Integrated HD Graphic 620 | Set from 1 to 255 minutes |
|
|
WLP-7F20-22 |
Available upon quote | 100V~240V (standard AC adapter included) / 47~63Hz |
・Realtek Audio Codec ・2+2 W power up |
Audio Line-Out and Microphone In | Intel 7th Generation Core-i5-7200U-2.5GHz [Built-in Intel HD Graphics 620] | SoC | DC power supply: +12V ~ 28V universal (DC cable optional) | SATA 3 controller | Mini PCIe socket x 2 (internal slot: wireless LAN card and other devices can be used at the same time) |
・Approx. 584.2mm x 364.6mm x 91.5mm (approx. 10kg: excluding AC adapter) ・With VESA standard 75 x 75 mm pit mounting holes (on the back of the main unit) |
DP (Display Port) x 2 ports (can output to two independent monitors) | RJ-45 connector (IEEE 10/100/1000 Base-Tx Fast Ehernet) x 2 slots | 2x Intel Gigabit Ethernet | 21.5” TFT color (Full HD resolution: 1,920 x 1,080) with LED backlight | When power is on: lights up in green, when HDD is accessed: flashes in orange | DDR4 SODIMM socket x 2 slots: Standard 4GB (expandable up to 32GB) | 10%~90% (no condensation) |
・0℃~40℃ (natural convection) ・0℃~50℃ (Forced convection of 1.0m/s according to IEC60068-2-56 standard at DC12V input) |
Non-locking push button, for power ON/OFF (when the power is turned on, pressing the button once will issue a shutdown command and turn the power off) | Approx. 65 W (maximum, excluding AC/DC adapter) | D-Sub 9-pin connector x 3 ports (1 port can be switched to RS-232/422/485 in BIOS) | Equipped with 1 x 2.5" Serial ATA HDD: 500GB standard (can be changed to flash memory SSD as an option) |
・Windows 10 IoT Enterprise 2019/2021 LTSC 64bit ・Linux can be installed (However, the customer will need to provide their own support.) |
・Uses a highly durable resistive film type (5-wire type: key press life approximately 36 million times) touch panel ・Option: Equipped with projected capacitive touch panel (4 points/multi) [7H surface hardness, 100 million keystroke life] |
4 USB 3.0 ports | Intel Integrated HD Graphic 620 | Set from 1 to 255 minutes |
Click on the part number for more information about each product
