Color TV format CMOS board model STC-S133 series
Omron Sentech Co., Ltd.
About This Product
■Summary
1/3.2 type 650,000 pixel TV format color CMOS board camera
■Features
A small board camera equipped with a Sony CMOS sensor. Due to its small size, it can be installed even in narrow spaces. You can choose the lens mount from no mount, fixed focus lens, or CS mount.
*Other model numbers are available.
-
Product
Color TV format CMOS board model STC-S133 series
-
Handling Company
Omron Sentech Co., Ltd.
-
Categories
10 Models of Color TV format CMOS board model STC-S133 series
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Case/board | Cell size (H x V, μm) | Effective number of pixels (H x V, pixels) | Filter | Imaging method | Lens mount | Monochrome/color | Remarks | Resolution | Sensor | Sensor size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
STC-S133N |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | Dual pass filter | NTSC | No lens mount | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-NF |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | No filter | NTSC | No lens mount | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-L |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | Dual pass filter | NTSC | S | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-LS |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | Dual pass filter | NTSC | S | Color | With fixed washer | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-CS |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | Dual pass filter | NTSC | CS | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-I |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | IR cut filter | NTSC | No lens mount | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-IL |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | IR cut filter | NTSC | S | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-ILS |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | IR cut filter | NTSC | S | Color | With fixed washer | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-ICS |
Available upon quote | Board | 3.5 x 3.5 | 1,280 x 486 | IR cut filter | NTSC | CS | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
|
|
STC-S133N-AL |
Available upon quote | Case | 3.5 x 3.5 | 1,280 x 486 | Dual pass filter | NTSC | S | Color | - | 650,000 pixels | ISX017 | 1/3.2 type |
Click on the part number for more information about each product
