  4. Aluminum bridge conveyor (Heisouki Co., Ltd.)
Aluminum bridge conveyor-BRA-3807
Aluminum bridge conveyor-Heisouki Co., Ltd.

Aluminum bridge conveyor
Heisouki Co., Ltd.

Heisouki Co., Ltd.'s Response Status

Response Rate

100.0%

Response Time

115.7hours

About This Product

■Terauchi Seisakusho aluminum bridge conveyor

The leg struts can be expanded and contracted at a pitch of 6mm. ・Reduces the labor of transporting cargo ・Foldable and convenient to carry ・Made of aluminum, lightweight - Stable installation even on steps and slopes.

■Characteristics of bridge conveyor

- The lightweight aluminum roller conveyor is equipped with foldable and extendable aluminum legs, so it can be easily installed and used wherever you want to use it. - All four legs have props that extend and contract at a 6mm pitch, allowing the conveyor to be installed stably even in places with steps or slopes. ・Aluminum parts are anodized to improve corrosion resistance and wear resistance.

  • Product

    Aluminum bridge conveyor

Share this product


460+ people viewing

Last viewed: 41 minutes ago

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

6 Models of Aluminum bridge conveyor

Click on the part number for more information about each product

Image Part Number Price (excluding tax) Allowable load Own weight Wall thickness (mm) Machine height (mm) Captain (mm) Material Folding storage dimensions Overall width (mm) Roller load capacity (kg/piece) Roller diameter (mm) Roller width (mm) Frame allowable load (N) Pitch (mm)
Aluminum bridge conveyor-Part Number-BRA-3807

BRA-3807

Available upon quote

100kgf

19.5kg

1.4

630~935

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×161

537~593

36

38.1

350

980

75

Aluminum bridge conveyor-Part Number-BRA-3810

BRA-3810

Available upon quote

100kgf

17.5kg

1.4

630~935

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×161

537~593

36

38.1

350

980

100

Aluminum bridge conveyor-Part Number-BRA-3815

BRA-3815

Available upon quote

100kgf

15.3kg

1.4

630~935

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×161

537~593

36

38.1

350

980

150

Aluminum bridge conveyor-Part Number-BRA-4507

BRA-4507

Available upon quote

100kgf

22kg

1.6

630~938

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×164

537~593

36

45

350

980

75

Aluminum bridge conveyor-Part Number-BRA-4510

BRA-4510

Available upon quote

100kgf

19kg

1.6

630~938

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×164

537~593

36

45

350

980

100

Aluminum bridge conveyor-Part Number-BRA-4515

BRA-4515

Available upon quote

100kgf

19kg

1.6

630~938

2,000

Legs, frame, roller pipe: Hard aluminum, bearing, shaft, bolt: Steel

2,000×537×164

537~593

36

45

350

980

150
