About This Product

TAKMill is a simple cutting machine that was developed for people who have no experience in cutting in the development, research, and design fields of manufacturing, and for those who want to easily create things like a 3D printer, by eliminating the difficult functions unique to machine tools and allowing anyone to express the intuition and tips of a craftsman.

■Do you have any of these problems?

・I use a 3D printer, but processing seems difficult and dangerous. ・I want to pass on difficult processing techniques and know-how to younger personnel. ・I want to create an environment for in-house production, but I want to keep the price as low as possible. ・The installation location is limited and I don't want to take up much space. TAKMill solves all these challenges.

■Equipped with "assist mode"

It is equipped with a newly developed "Assist Mode" that allows for simpler and smoother operation of the conventional UI "mico" developed by our company. Just follow the simple steps suggested by the machine and you will have everything you need to prepare for cutting. TAKMill will guide you from selecting the machining program to adjusting the feed rate and setting the workpiece.

■No need to measure tool length

When measuring tool length, the disadvantages are that it takes time for those who are inexperienced in machining, requires learning how to do it, machining failure due to measurement errors, and in some cases, damage to the machine in the worst case. TAKMill is programmed to automatically perform these steps, completely eliminating the need for tool length measurement.

  • Product

    Cutting machine Cutting machine for light users TAKMill mini

Share this product


40+ people viewing


Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

1 Models of Cutting machine Cutting machine for light users TAKMill mini

Image Part Number Price (excluding tax) ATC Other standard features Safety Table size Spindle power Spindle rotation speed Spindle type Positioning accuracy Control machine Processing data transfer Processing material Operating range External dimensions Tool protrusion length Required air pressure source Maximum operating speed Mechanical resolution Repeated positioning accuracy Weight Power supply, power consumption Option Accessories
Cutting machine Cutting machine for light users TAKMill mini-Part Number-TAKMill mini

TAKMill mini

Available upon quote

6 fixed direct type

Air blow, door interlock, automatic tool length measuring device, automatic power cutoff

Door interlock

X420mm Y370mm

Built-in type 350W

5,000-60,000rpm
*3,000-30,000rpm (high torque specification)
*500 rpm can be set only during centering work

NR3060-AQC

0.050mm/300mm

Mico (original controller)

LAN, USB

Aluminum (gypsum, ABS, chemical wood, light load metal)

X400mm Y350mm Z200mm

Body: W800mm D930mm H870mm

95mm from the spindle end face
Example) If the holder is 21mm, the blade protrusion is 74mm.

When using ATC: 0.6Mpa 50L/min or more
When using air blow (maximum): 0.6MPa 80L/min

3,000mm/min (G00 G01)

0.001mm

±0.010mm

Body: 180Kg

Single phase AC100V 15A with 2P grounding
Single phase AC200V 15A with 2P grounding

Oil mist, coolant, signal tower, A-axis unit, sub-table, tool set, clamp kit, dust collection duct opening

Operating instructions
