About This Product

■Wastewater treatment plant controller - N2O concentration and emission rateThe wastewater treatment plant controller is operated via a TFT touch screen and can receive input from up to two wastewater treatment plant N2O sensors. The controller displays temperature-compensated N2O signal levels from both sensors, emission rate and process temperature. The controller comes with an optional USB data logger, allowing data to be collected without being connected to a PLC/SCADA system.

Emission rates are calculated in the controller using standard fixed model parameters. To obtain more accurate emission values, dynamic input parameters can be used in the add-on emission module. Sensor calibration is recommended on a bi-monthly basis and is performed on-site via the controller's menu system and according to the calibration manual provided with the N2O Calibration Kit for Wastewater Treatment Plants.

The controller comes standard with a mounting plate, and optional pipe mounting kits and rain protection can be ordered.

■Other outputs・Internet, ModBus (serial or TCP)
・Option: Temperature sensor for wastewater plant x 2
・Option: PROFIBUS-DP
・Optional: USB data logging – separate software required

Model
There is 1 model available for this product.

Product
Nitrous oxide (N2O) measurement system for wastewater treatment plants Controller for wastewater treatment plants

Handling Company
Central Scientific Trading Co., Ltd.

Categories

Meters & Instruments

Turbidimeters

30+ people viewing

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

1 Models of Nitrous oxide (N2O) measurement system for wastewater treatment plants Controller for wastewater treatment plants

Image	Part Number	Price (excluding tax)	Other input	Case (exterior)	Controller display	Sensor input	Sensor output	Sensor emission rate output	Attachment	Size	Mass	Electrical safety	Power supply
	Controller for wastewater treatment plant	Available upon quote	Options: Airflow (m3/h), 4-20mA Options: Airflow ON/OFF (binary input - potential-free contact) ×2	Plastic surface mount case (made by ABC), IP67	TFT touch screen controller	2 N2O sensors for wastewater treatment plants with built-in temperature sensor	Temperature corrected N2O value (N2O-N [mg/L]) ×2	Emission calculation using standard fixed model parameters (N2O-N [mg/m3/d]) ×2 Optional: dynamic input parameters	Pipe can be installed using multiple fixing holes, rain protection equipment and pipe installation kits	301.5×283.2×120.5 mm	3.2kg	Compliant with EN61010, part 1 overvoltage category III, pollution degree 2	AC110~240V+10/15%, 48~63Hz
