Crimp terminal cross-section analysis system CS-07 enables analysis of all crimp terminal samples-CS-07

Crimp terminal cross-section analysis system CS-07 enables analysis of all crimp terminal samples
Cosmonet Co., Ltd.

About This Product

All cross-sectional observation processes are integrated, and cutting, polishing, and analysis can be performed in one system. The cross section of the crimp terminal can be observed without hardening the resin, so the work can be completed in about 1 minute. Equipped with a touch panel and an excellent user interface, anyone can work safely and easily.

■Fully automatic cutting and polishingEquipped with a stepping motor for conveyance, cutting and polishing is performed fully automatically. Eliminates manual work errors.

■Extremely thick line cutCompatible with extra-thick wires from 5sq to maximum 60sq. A vacuum unit sucks in dust and creates a clean cross section just by cutting.

■Equipped with measurement position check cameraBy using the front/rear adjustment dial while looking at the monitor, you can accurately determine the measurement position.

■Vertical section cutVertical cross-section samples can be created without resin hardening. Using a special clamper and cutting blade, it is compatible with sizes from 0.18sq to 2sq.

■Analysis cameraThe created sample can be placed directly under the USB camera while still mounted on the jig, and images can be taken as is. Positioning can be easily adjusted using positioning pins and an XY stage.

■Zoom lens with LED lightingIt uses a zoom lens with an optical magnification of 0.7 to 4.5 times. The maximum field of view is W12.7mm*H9.2mm (0.7x). The minimum is W2.0mm*1.5mm (0.45x). The longer WD of 88mm makes etching easier. The lighting uses white LEDs, and the brightness can be changed from the LCD panel on the main unit.

Model
There is 1 model available for this product.

Product
Crimp terminal cross-section analysis system CS-07 enables analysis of all crimp terminal samples

Handling Company
Cosmonet Co., Ltd.

Categories

Testing Equipment

Visual Inspection Systems

20+ people viewing

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

1 Models of Crimp terminal cross-section analysis system CS-07 enables analysis of all crimp terminal samples

Image	Part Number	Price (excluding tax)	Cutting wheel dimensions	Microscope lens	Finish polishing plate dimensions	Outer diameter dimension	Supported languages	Analysis camera	Applicable wire size	Weight	Power supply	Drive method
	CS-07	Available upon quote	Ф95mm×0.5mm	Magnification 0.7x~4.5x (angle of view 12.7mm x 9.2mm x 2.0mm x 1.5mm)	Ф120mm (particle size 1200)	W500mm×D522mm×H693mm	Japanese/English	1.3 million pixel USB camera	0.05sq-60.0sq (AWG30~AWG1/0)	50kg	AC100V or 240V (50/60Hz)	Cut polishing: DC motor, conveyance: stepping motor
