Rust-proof, all stainless steel specifications, complete standard equipment, digital control type mold temperature controller TT series
Stolz Co., Ltd.
About This Product
■All stainless steel internal piping with high rust prevention performance
・Circulation pump all stainless steel specifications (impeller housing)
・All stainless steel piping specifications meet the need for rust prevention.
■Excellent discharge performance and accurate PID temperature control
Adopts a high pressure and high flow rate pump. PID control provides highly efficient and accurate temperature control. It has a low-noise design with quiet operation, contributing to a comfortable working environment. The controller has digital settings and digital display. It has high operability.
■Complete standard equipment
・Air purge
・Return medium temperature display
・SSC heater control
・Glycerin-filled pressure gauge
・Bypass valve
・Full opener panel
・Cooling operation stopped
・Trip type earth leakage breaker
・Heat insulation control box with NAC structure
・4-point brake casters
-
Product
Rust-proof, all stainless steel specifications, complete standard equipment, digital control type mold temperature controller TT series
-
Handling Company
Stolz Co., Ltd.
-
Categories
1 Models of Rust-proof, all stainless steel specifications, complete standard equipment, digital control type mold temperature controller TT series
| Product Image | Part Number | Price (excluding tax) | Accessories | Controller Temperature control method | Controller alarm | Controller setting display method | Controller temperature detection method | Controller timer | Cooling method | External dimensions (WxDxH) (mm) | Heat medium | Heater control method | Heater power (kW) | Heater type | Mass (kg) | Piping standards Compressed air inlet | Piping standards Cooling water inlet/outlet (common) | Piping standards Medium delivery port/return port (common) | Power plug (hook type plug) | Power supply standard | Pump maximum flow rate (L/min) | Pump maximum pressure (MPa) | Pump motor power (kW) | Pump type | Required cooling water (L/min) | Temperature setting range (℃) | Total electrical capacity (50/60Hz) (kVA) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
TT-02 |
Available upon quote | Power cable 5m | Heating PID/cooling proportional control | Pump overload, insufficient water supply pressure, overheat prevention, sensor disconnection, reverse phase error, upper temperature limit/lower temperature limit | Touch key/digital display | Thermocouple JISK (transporting medium side) | Setting range: 0~99 hours (ON after set time) | Direct cooling | 270x720x590 | Shimizu | SSR | 6 | Sheathed heater | 60 | 10A (3/8B) | 15A (1/2B) | 10A (3/8B) ×4 | Without plug 30A | 200/220V 50/6/Hz 3φ | 80/100 | 0.35/0.48 | 0.75/0.75 | Multi-stage spiral type | 15 | Water supply temperature +10℃~maximum 120℃ (accuracy: ±1) | 7.62 |
