Battery Protector that protects the battery installed in a camper from over-discharge.
Adcon Co., Ltd.
About This Product
■Functions and features
Many conventional battery proctors use relays in the load connection control section, so the relays waste power all the time when the load is turned on. This product is an eco-friendly product that reduces wasteful power consumption to the bare minimum and allows you to use your battery efficiently and safely.
If the battery installed in the vehicle cannot be charged from an external power source or generator, it can be charged while driving or by installing a solar panel. It is very annoying when the power stored in the battery is unconsciously consumed without any use. Also, even if you spend a lot of money installing a solar charging system, you won't be able to charge it on rainy days or at night. Moreover, even on sunny days, you can only charge the battery for about 5 hours a day.
Simply replacing the conventional product with this device (battery protector) is worth more than one solar panel. It is cheaper and easier to install than solar systems.
■Prevents unnecessary battery consumption
The standby power when the main unit is turned on is about 0.3 watts.
■Incorporates an abnormal temperature safety device for the control section.
If the heat sink continues to exceed 50℃ for 60 seconds or more, the load will be disconnected.
■Informs you with a buzzer and light when the voltage drops.
When the battery voltage falls below 11.5V, a warning buzzer (beep) will sound once every 30 seconds and the blue lamp will turn on. When the battery voltage falls below 11.0V, the SOS buzzer (beep beep beep...) will sound and the red lamp will turn on. And the load will be disconnected within 30 seconds.
■When the radiator becomes high temperature, a buzzer sound and light will notify you.
When the temperature of the radiator exceeds 50℃, the SOS buzzer (beep beep beep...) will sound and the yellow lamp will flash. If the temperature does not drop after 60 seconds, disconnect the load.
■Package contents
・1 unit
・Plastic external mounting feet (already attached to the main unit) 4 pieces
・Terminal mounting screws (M4×5 round screws) 8 pieces
-
Product
Battery Protector that protects the battery installed in a camper from over-discharge.
-
Handling Company
Adcon Co., Ltd.
-
Categories
1 Models of Battery Protector that protects the battery installed in a camper from over-discharge.
| Product Image | Part Number | Price (excluding tax) | Abnormal temperature stop (℃) | Case | Connection terminal | Connection wire | Contact resistance value On resistance (mΩ) | Main unit current consumption when ST OFF (mA) | Maximum allowable control capacity LOAD+ to load (W) | Maximum allowable load current LOAD+ to load (A) | Minimum allowable load current (mA) | No-load current of main unit when SW ON (mA) | Operating environment temperature (℃) | Operating time Switch ON to LOAD ON (mSec) | Output capacitance (PF) | Radiator | Rated voltage Battery input voltage (V) | Temperature measurement accuracy (degrees) | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
Battery Protector Battery Protector |
Available upon quote | When the temperature of the radiator is 50 or higher | ABS resin case | Terminal outer diameter 7Φ gold plated, mounting screw M4-5 round screw, crimp terminal R5.5-4 | GND, LOAD+, BATT+ terminals are 5.5 square mm or more SW+, SW terminals are 1.25 square mm or more | 7 (Voltage drop at 30A is 0.21V) | Approx. 0.5 (at 12.0V) | 370 | 30 | 10 | Approx. 15.6 (at 12.0V) | -5~40 | Up to 1,000 | 5,800 | Aluminum heat sink | 11.2~14.0 | ±3 | Approximately 405 |
