Physical and chemical equipment oxygen measurement system Oxygen measurement introductory system Oxyview1Handling Company
Asahiko Trading Co., Ltd.Categories
Usage Scenarios
Chemical Industry Use| Image | Part Number | Price (excluding tax) | Power supply | Electrode type | Electrode output | Oxygen consumption | Suitability | Measuring range | Temperature control | Residual current | Structure | Response time | Size | External dimensions | Resolution | Polarization voltage | Signal input | Plunger | Back off | Sample amount | Sample chamber | Gain | Analog output | Oxyview1 electrode control unit weight | DW1/AD Electrode Chamber Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
Oxyview1 |
Available upon quote |
95~260V universal input mains power, output 12V DC 2.5A |
Clark type polarographic oxygen sensor |
Typical 1.6μA at 21% O2 |
Usually <0.015μmol/hr^-1 |
Liquid phase respiration/photosynthesis |
Oxygen: 0~100% |
Water jacket connected to circulating constant temperature water tank (required separately) |
Typical 0.04μA in 0% O2 |
Acrylic |
10~90%, usually less than 5 seconds |
65×105mm |
90×135×85mm |
10x10-6μmols/ml at 20℃ |
Selectable between 0.4~0.9V (0.7V is recommended by default) |
S1 O2 electrode (SMB) |
Height-adjustable plunger assembly with central bore for sample addition |
Back off signal in 1mV steps |
0.2~2.5ml |
Glass tube |
Coarse adjustment: ×1, ×2, ×5, ×10, ×20, ×50, ×100, fine adjustment: 1mV step |
0~5V electrode signal |
320g |
100 grams |
