Horizontal machining center Table feed type machining center D series
Hocos Co., Ltd.
About This Product
■ATC device (auto tool changer)
When using tools for precision measurement, etc., we have prepared a tool change speed override function to avoid shock when changing tools. Tools that use tool change override can be supported by registering them in advance.
■APC device (auto pallet changer)
By adopting a two-sided restraint system, we have achieved high precision positioning and high rigidity of the pallet. The pallet positioning section prevents chips from adhering to it by blowing air from inside.
■Unmanned and labor-saving compatible (optional)
By using a multi-sided pallet changer (optional) such as an endless rotary conveyor system or a three-dimensional pallet stocker system, unmanned operation can be performed for long periods of time.
-
Product
Horizontal machining center Table feed type machining center D series
-
Handling Company
Hocos Co., Ltd.
-
Categories
1 Models of Horizontal machining center Table feed type machining center D series
| Product Image | Part Number | Price (excluding tax) | Cutting feed rate | Installation space | Maximum loading weight | Maximum spindle speed | Number of tools stored | Rapid traverse speed | Tool shank | Travel amount X axis | Travel amount Y-axis | Travel amount Z axis | Workpiece mounting area |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
DM70H |
Available upon quote | 1~10,000mm/min | 2,200mm×5,095mm | 500kg | 12,000min-1 (15,000min-1) |
[Z: 650 stroke] 495mm (BT40) [Z: 1,000 strokes] 595mm (BT40) |
62m/min (0.7G) | BT40 (HSK-A63, KM6350) | 650mm (1,100mm) | 730mm | 650mm (1,000mm) | Φ730×900mm |
