Tabletop precision coating device ED20
Engineering Lab Co., Ltd.

About This Product

■Product overview

The tabletop precision coating device ED20 is a compact tabletop model (W500 x D800mm) that is ideal for research and development and prototyping. By adopting an X-Y stage, the repeatable positioning accuracy of the XY axes is guaranteed to be less than ±3μm, making it the industry's highest-class accuracy for a tabletop robot. In addition to the twin air dispenser (full function, basic function), it can be equipped with any dispenser such as a piezo jet dispenser or screw dispenser, so it can be used in a wide range of prototyping applications. Equipped with a top view camera, laser displacement meter, and vacuum suction stage, it comes standard with automatic alignment and workpiece height measurement functions essential for high-precision coating. This model is also ideal as an experimental machine for research and development for fine coating and liquid agent evaluation.

  • Product

    Tabletop precision coating device ED20

Share this product


60+ people viewing

Last viewed: 4 hours ago

Free
Get started with our free quotation service - no cost, no obligation.

No Phone Required
We respect your privacy. You can receive quotes without sharing your phone number.

1 Models of Tabletop precision coating device ED20

Image Part Number Price (excluding tax) Equipment size, weight Image software features Onboard equipment Mountable work size Equipped with dispenser Utility Optional mechanism Z maximum speed XY maximum speed XY stroke XYZ drive resolution XYZ repeat positioning accuracy
Tabletop precision coating device ED20-Part Number-ED20

ED20

Available upon quote

W500xD800xH980mm Weight: 100kg or less

Drawing data creation function, auto alignment, DXF import function, etc.

Top view camera, laser displacement meter, vacuum suction stage, interlock mechanism

200x200mm or less, t=6mm or less

Twin air dispenser, piezo jet dispenser

Power supply 100Vx700W, clean dry air: 0.5Mpa, vacuum

Side view camera, nozzle cleaning unit, nozzle tip position detection unit, vacuum pump, console box, stainless steel workbench

30mm/s

50mm/s

X direction: 200mm, Y direction: 200mm (stage drive)

1μm

±3μm
