Compact servo press SPC model
ESTIC CORPORATION
About This Product
Estic's servo press was developed using the control technology of the servo motor cultivated in the development of electric nutranna. Traceability is perfect because you can collect various data on pressurization. Not only the load but also the time and position data, so that the pressure is poor is detected. Because of electric driving, it enables clean and energy -saving pressure compared to hydraulic and empty pressure.
The compact servo press SPC model is a compact model that supports a narrow part that uses a guide key and bush for the lamb guide.
4 types of control mode
･ Simple programming specifications that select an appropriate control method from four modes set in advance and enter the set value.
･ By using management software (options), the start time can be reduced further.
Monitor (zone judgment) function
･ Monitor (Zone Judgment) Function function A function to determine the load up and down in any position in the middle of the operation.
-As standard equipment: [Section monitor function] based on the starting point and [back monitor function] based on the operation completion point.
･ It can be selected according to the work characteristics and the user's management method.
Dynamic stall (D-ST) function
･ Feedback from the built -in tooled road cell to the operating control of the servo motor in real time.
･ A function that can maintain a constant load pressure by controlling while following the load fluctuation of the work.
compact
･ Realize compactness of the same size as hydraulic press by downsizing.
･ Contributing to spacing the pressure of pressure.
Environmental consideration
･ Servo motor driving reduces energy consumption and is excellent in silence.
(Energy consumption is about 10 to 20%compared to general air type and oil type)
Improvement of productivity
-Cycle time is optimized by controlling the load, position, speed, and time.
･ Feed back the operation status in real time to prevent work damage.
Productivity maintenance
･ Gear drive adoption makes it easy to maintain productivity without any frame/belt extension/belt in the belt drive.
Easy setup
-The short -time setup is possible with the simple unit configuration of the tool, controller and cable and the excellent usability.
Safety design
･ The output shaft drop prevention brake for preventing the power supply is standard equipment.
-
Product
Compact servo press SPC model
-
Handling Company
ESTIC CORPORATION
10 Models of Compact servo press SPC model
Items marked with have different values depending on the model number.
Click on the part number for more information about each product
| Product Image | Part Number | Price (excluding tax) | Brake holding load (N) | Conforming controller | Maximum pressurization speed (mm/s) | Maximum shipping speed (mm/s) | Maximum stroke (mm) | Mounting specification | Press continuous rating (kn) | Press maximum thrust (kn) | Repeated load accuracy | Repeated position accuracy (mm) | Total length (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
SPC010-20 |
Available upon quote | 196 (20kg) | SPU50C-40 | 120 | 200 | 200 | No flange | 4.1 | Ten | 3σ/x-bar ≦ 1.5% | ± 0.01 | 545 | 13 |
|
|
SPC010-20-F |
Available upon quote | 196 (20kg) | SPU50C-40 | 120 | 200 | 200 | With a flange | 4.1 | Ten | 3σ/x-bar ≦ 1.5% | ± 0.01 | 545 | 14 |
|
|
SPC020-20 |
Available upon quote | 294 (30kg) | SPU50C-5K | 220 | 310 | 200 | No flange | 7.5 | 20 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 650 | 35 |
|
|
SPC020-20-F |
Available upon quote | 294 (30kg) | SPU50C-5K | 220 | 310 | 200 | With a flange | 7.5 | 20 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 650 | 36 |
|
|
SPC030-20 |
Available upon quote | 490 (50kg) | SPU50C-5K | 155 | 235 | 200 | No flange | 10.4 | 30 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 745 | 49 |
|
|
SPC030-20-F |
Available upon quote | 490 (50kg) | SPU50C-5K | 155 | 235 | 200 | With a flange | 10.4 | 30 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 745 | 51 |
|
|
SPC050-20 |
Available upon quote | 980 (100kg) | SPU50C-5K2 | 170 | 255 | 200 | No flange | 25.1 | 50 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 862 | 110 |
|
|
SPC050-20-F |
Available upon quote | 980 (100kg) | SPU50C-5K2 | 170 | 255 | 200 | With a flange | 25.1 | 50 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 862 | 117 |
|
|
SPC100-20 |
Available upon quote | 1960 (200kg) | SPU50C-5K2 | 100 | 151 | 200 | No flange | 42.5 | 100 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 977 | 145 |
|
|
SPC100-20-F |
Available upon quote | 1960 (200kg) | SPU50C-5K2 | 100 | 151 | 200 | With a flange | 42.5 | 100 | 3σ/x-bar ≦ 1.5% | ± 0.01 | 977 | 153 |
